ELECTRICAL 1

ELECTRICAL 2 FOR YAMAHA EVOLIS 1994

CDI UNIT ASSY

3KJ855400100

3KJ855401000

69,00 $

Unit Price

IGNITION COIL ASSY

3YJ823100000 3YJ823100000

Not available

BOLT, HEXAGON DEEP RECESS

970010601600

97D950601600

1,96 $

Unit Price

PLUG CAP ASSY

56J823700000 56J823700000

41,76 $

Unit Price

SEAL, PLUG CAP

3KJ823720000 3KJ823720000

4,18 $

Unit Price

BAT YB4L-B YU NA

4CUH21100000

YB4LB0000000

46,24 $

Unit Price

HOSE (L1500)

904450804800

90445084J000

21,15 $

Unit Price

BOX, BATTERY

4CUF177G0000 4CUF177G0000

Not available

BRACKET 1

4CUF172K0000 4CUF172K0000

Not available

WIRE HARNESS ASSY

4FX825900000 4FX825900000

Not available

OIL LEVEL GAUGE ASSY

4CUH57200000 4CUH57200000

Not available

RELAY ASSY (29U-93)

29U819509300 29U819509300

49,08 $

Unit Price

CLAMP

904651814700 904651814700

4,03 $

Unit Price

RESISTOR ASSY

2JA853700000 2JA853700000

Not available

SCREW, PAN

985010601400

985070601400

2,10 $

Unit Price

SENDER UNIT ASSY, FUEL

4CU857520000 4CU857520000

Not available

GASKET, SENDER UNIT

5G3857530000 5G3857530000

17,07 $

Unit Price

BOLT, WITH WASHER

901190507100 901190507100

3,58 $

Unit Price

REAR REFLECTOR ASSY

3NCH51300000 3NCH51300000

Not available

NUT, FLANGE(3GM)

957060550000

957070550000

2,29 $

Unit Price

NUT, FLANGE(7NB)

957020650000

957800650000

3,18 $

Unit Price

BOLT, LEG SHIELD

4CUF83310000 4CUF83310000

Not available

SCREW PAN HEAD

985020601600

985800601600

2,35 $

Unit Price

FUSE

27V821510000 27V821510000

2,09 $

Unit Price

SCREW (5G3)

901530603400 901530603400

3,22 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the ELECTRICAL 2 of your Yamaha YE50 of 1994. Let us know if you have any questions.
