CYLINDER

CRANKSHAFT / PISTON FOR YAMAHA KODIAK 2018

VALVE

Item numbers

CRANKSHAFT ASSY

BB5114000000

BB5114000100

888,83 $

Unit Price

CRANK SUB ASSY 1

BB5114010900 BB5114010900

673,94 $

Unit Price

CRANK SUB ASSY 2

5ND114020900 5ND114020900

428,84 $

Unit Price

PIN, CRANK 1

BB5116810000 BB5116810000

88,97 $

Unit Price

BEARING, CYLINDRICAL (3TB)

93310635D400 93310635D400

138,76 $

Unit Price

WASHER, PLATE(1XL)

90201356K100 90201356K100

16,42 $

Unit Price

ROD, CONNECTING

5GH116510100 5GH116510100

202,04 $

Unit Price

SEAL, CRANK

5GH114470000 5GH114470000

48,01 $

Unit Price

KEY, WOODRUFF

902800504800

902800500100

13,31 $

Unit Price

WASHER, PLATE

902011402800 902011402800

23,72 $

Unit Price

NUT

901791431700 901791431700

22,18 $

Unit Price

BEARING(4GB)

933063062900 933063062900

99,23 $

Unit Price

PISTON (STD)

5ND116310000

5ND1163100YX

118,56 $

Unit Price

PISTON (0.50MM O-S)

5ND116360000 5ND116360000

141,72 $

Unit Price

PISTON (1.00MM O-S)

5ND116380000 5ND116380000

141,72 $

Unit Price

PISTON RING SET (STD)

5ND116030000 5ND116030000

71,16 $

Unit Price

PISTON RING SET (0.50MM O-S)

5ND116050000 5ND116050000

69,96 $

Unit Price

PISTON RING SET (1.00MM O-S)

5ND116070000 5ND116070000

69,96 $

Unit Price

PIN, PISTON

3LD116330000 3LD116330000

22,70 $

Unit Price

CIRCLIP 341116340000

934502202700 934502202700

4,86 $

Unit Price

BALANCER ASSY

5ND115000000 5ND115000000

391,39 $

Unit Price

BRG, R-B 6303 47MM 115G NK

933063031500

933063030200

32,05 $

Unit Price

BRG, R-B 6304C3 52MM 144G KY

933063043800

933063042100

26,73 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
