STEERING

FRONT FORK FOR YAMAHA XMAX 2018

FUEL TANK

Item numbers

FRONT FORK ASSY (L.H)

BL1F31020000 BL1F31020000

Not available

. TUBE, OUTER (L.H)

BL1F31260000 BL1F31260000

Not available

. INNER TUBE COMP.1

BL1F31100000 BL1F31100000

Not available

. CYLINDER COMP., FRONT FORK

BL1F31700000 BL1F31700000

Not available

SLIDE, METAL 1

4HC231252000 4HC231252000

18,05 $

Unit Price

OIL SEAL WASHER

22W23146L000 22W23146L000

9,64 $

Unit Price

OIL SEAL

5BPF31450000 5BPF31450000

31,62 $

Unit Price

RING, SNAP

22WF3156L000 22WF3156L000

9,91 $

Unit Price

SEAL, DUST

5BPF31440000 5BPF31440000

37,31 $

Unit Price

SPACER, OIL LOCK

2CMF31660000 2CMF31660000

13,77 $

Unit Price

GASKET

2BUF31580000 2BUF31580000

3,49 $

Unit Price

278-23181-50-00 *

31BF31810000 31BF31810000

8,47 $

Unit Price

. SPRING, FRONT FORK

BL1F31410000 BL1F31410000

Not available

WASHER, SPRING UPP

2JKF31490100 2JKF31490100

7,92 $

Unit Price

SPACER

B74F31180000 B74F31180000

25,82 $

Unit Price

GASKET

2JKF31140000 2JKF31140000

5,01 $

Unit Price

BOLT, CAP

5BPF31111000 5BPF31111000

48,10 $

Unit Price

FRONT FORK CAP

2N4231680000 2N4231680000

8,13 $

Unit Price

FRONT FORK ASSY (R.H)

BL1F31030000 BL1F31030000

Not available

. TUBE, OUTER 2

BL1F31360000 BL1F31360000

Not available

. INNER TUBE COMP.1

BL1F31100000 BL1F31100000

Not available

. CYLINDER COMP., FRONT FORK

BL1F31700000 BL1F31700000

Not available

SLIDE, METAL 1

4HC231252000 4HC231252000

18,05 $

Unit Price

OIL SEAL WASHER

22W23146L000 22W23146L000

9,64 $

Unit Price

OIL SEAL

5BPF31450000 5BPF31450000

31,62 $

Unit Price

RING, SNAP

22WF3156L000 22WF3156L000

9,91 $

Unit Price

SEAL, DUST

5BPF31440000 5BPF31440000

37,31 $

Unit Price

SPACER, OIL LOCK

2CMF31660000 2CMF31660000

13,77 $

Unit Price

GASKET

2BUF31580000 2BUF31580000

3,49 $

Unit Price

278-23181-50-00 *

31BF31810000 31BF31810000

8,47 $

Unit Price

. SPRING, FRONT FORK

BL1F31410000 BL1F31410000

Not available

WASHER, SPRING UPP

2JKF31490100 2JKF31490100

7,92 $

Unit Price

SPACER

B74F31180000 B74F31180000

25,82 $

Unit Price

GASKET

2JKF31140000 2JKF31140000

5,01 $

Unit Price

BOLT, CAP

5BPF31111000 5BPF31111000

48,10 $

Unit Price

FRONT FORK CAP

2N4231680000 2N4231680000

8,13 $

Unit Price

UNDER BRACKET COMP

B74F33400000 B74F33400000

569,01 $

Unit Price

BOLT 1

2JKF33460000 2JKF33460000

13,17 $

Unit Price

BEARING (3FV)

933999993200 933999993200

69,64 $

Unit Price

STEERING SEAL

3FV234620000 3FV234620000

22,89 $

Unit Price

COVER, UNDER 1

B65F31230000 B65F31230000

2,95 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
