CAMSHAFT / TIMING CHAIN FOR YAMAHA XMAX 2013

WATERPUMP / HOSES

ARBRE A CAMES 1

1SDE21710000 1SDE21710000

Not available

PIGNON, CHAINE DE DISTRIBUTION

1SDE21760000 1SDE21760000

Not available

BOULON

9010507X0000 9010507X0000

Not available

ARBRE A CAMES 2

1SDE21810000 1SDE21810000

Not available

DECOMPRESSEUR COMPLET

1SDE22800000 1SDE22800000

Not available

BOULON

9010507X0000 9010507X0000

Not available

DECOMPRESSION CAM

5TA122880000 5TA122880000

21,49 $

Unit Price

DECOMPRESSION LEVE

5VK122900000 5VK122900000

53,61 $

Unit Price

CHAIN 136L

945821813600 945821813600

41,35 $

Unit Price

GUIDE, BUTEE 1

1SDE22310000 1SDE22310000

Not available

PLAQUE, GUIDE BUTEE 1

1SDE22330000 1SDE22330000

Not available

STOPPER GUIDE 2

5RU122410000 5RU122410000

107,75 $

Unit Price

AXE 2

1SDE22570000 1SDE22570000

Not available

PLAQUE, GUIDE BUTEE 2

1SDE22430000 1SDE22430000

Not available

BOULON, TETE HEXAGONALE CREUSE

9011006X8600 9011006X8600

Not available

TENSIONER ASSY, CA

1B7122100000 1B7122100000

222,78 $

Unit Price

GASKET, TENSIONER

4FM122130000 4FM122130000

3,71 $

Unit Price

BOLT

913120602000 913120602000

3,84 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CAMSHAFT / TIMING CHAIN of your Yamaha XMAX 400 of 2013. Let us know if you have any questions.
