REAR WHEEL

HANDLEBAR & CABLES FOR YAMAHA KODIAK 1996

FRONT BRAKE MASTER CYLINDER

Item numbers

HANDLEBAR

3HN261110000 3HN261110000

94,53 $

Unit Price

GRIP (L.H)

3GB262410000 3GB262410000

22,53 $

Unit Price

HANDLEBAR PROTECTOR

4SH261240000

4SH261240100

91,82 $

Unit Price

THROTTLE CABLE

4SH263110000

4SH263110100

42,71 $

Unit Price

CABLE, BRAKE

4SH263410000 4SH263410000

100,81 $

Unit Price

NUT, AJUSTING

20E263430000 20E263430000

25,61 $

Unit Price

SPRING, COMPRESSION (29U)

905011078200 905011078200

5,66 $

Unit Price

PIN 1562723700

902491200800 902491200800

5,17 $

Unit Price

THROTTLE LEVER ASSY

1NV262500100 1NV262500100

254,64 $

Unit Price

CHAPEAU, PIGNON

1NV2628F0000 1NV2628F0000

Not available

LEVER, THROTTLE

1NV2625G0100

1NV2625G0200

93,05 $

Unit Price

SCREW, PAN

985070501200

985170501200

2,23 $

Unit Price

SCREW, PAN HEAD

985070502000

985170502000

1,04 $

Unit Price

NUT, U

956170510000 956170510000

5,12 $

Unit Price

NUT, HEXAGON SMALL

953070570000

953170570000

2,63 $

Unit Price

OIL SEAL (9X15X4-256)

931040902500 931040902500

7,30 $

Unit Price

SPRING

1NV263040000 1NV263040000

8,16 $

Unit Price

GASKET

1NV2628G0000 1NV2628G0000

6,53 $

Unit Price

WASHER

1NV261290000 1NV261290000

3,73 $

Unit Price

WASHER, SPECIAL

53L839090000 53L839090000

3,68 $

Unit Price

HOLDER, LEVER LOWER

4V4829130000 4V4829130000

21,64 $

Unit Price

SCREW, PAN HEAD

985070502000

985170502000

1,04 $

Unit Price

WASHER(3SX)

929070510000 929070510000

2,13 $

Unit Price

BOLT

901230804600

901230800200

14,75 $

Unit Price

ECROU

901790514800 901790514800

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the HANDLEBAR & CABLES of your Yamaha KODIAK 400 4WD of 1996. Let us know if you have any questions.
