KICK STARTER

PRIMARY SHEAVE FOR YAMAHA OVATION 1989

SECONDARY SHEAVE

Item numbers

SHEAVE, PRIMARY FIXED

84J176110000 84J176110000

124,17 $

Unit Price

PRIMARY SHEAVE, SLIDING

8V0176210100 8V0176210100

179,90 $

Unit Price

CAP

8V0176310000 8V0176310000

118,90 $

Unit Price

SPIDER, COMPLETE

82M176400100

82M176400200

256,94 $

Unit Price

STOPPER

8V0176390000 8V0176390000

13,52 $

Unit Price

SLIDER

8V0176530000

88X176530000

14,14 $

Unit Price

COLLAR(83R)

90387086G400

90387057W500

15,17 $

Unit Price

ROLLER, WITH BUSH

90387105V500

87MW176B1000

30,81 $

Unit Price

WASHER, PLATE(87G)

902020813800

902020820500

4,67 $

Unit Price

WASHER, CONICAL SPRING (8V8)

902080503600 902080503600

2,61 $

Unit Price

BOLT, HEXAGON

970220503500

970270503500

2,51 $

Unit Price

NUT, U

956120510000

956170510000

5,12 $

Unit Price

BOLT, HEXAGON

970120603000

970170603000

2,45 $

Unit Price

WASHER(6A1)

929900610000

929950610000

1,46 $

Unit Price

BOLT (L=156.5MM)

8V0176470000

8V0176471000

16,59 $

Unit Price

BUSH(83R)

903892802600

903892803200

64,07 $

Unit Price

PIN, DOWEL (8V8)

936074419000 936074419000

18,20 $

Unit Price

WASHER, PLATE (8V8)

90201077F500 90201077F500

3,34 $

Unit Price

WASHER(JN5)

929011610000

929071610000

16,15 $

Unit Price

BUSH (81H)

903894002900 903894002900

62,70 $

Unit Price

BUSH(83R)

903860816600 903860816600

28,32 $

Unit Price

WEIGHT

85L176320900

85LW176A0000

25,70 $

Unit Price

BUSH(83V)

903860715200 903860715200

22,07 $

Unit Price

SPRING, COMPRESSION

90501520A900 90501520A900

32,93 $

Unit Price

SPRING, COMPRESSION

90501554F600 90501554F600

Not available

SPRING, COMPRESSION

905015569100 905015569100

Not available

V-BELT

820176410000

820176410100

57,54 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the PRIMARY SHEAVE of your Yamaha Ovation II_LE of 1989. Let us know if you have any questions.
