FUEL TANK FOR YAMAHA XMAX 2017

SEAT

Item numbers

RESERVOIR A ESSENCE

B74F41100000 B74F41100000

Not available

CLAMP (4FM)

904641318500 904641318500

6,40 $

Unit Price

SEAL

5D9F414G0000 5D9F414G0000

1,80 $

Unit Price

BOLT, WITH WASHER

90119068A200 90119068A200

1,93 $

Unit Price

POMPE A CARBURANT COMP.

B74E39070000 B74E39070000

Not available

CLIP

3C1F45190000 3C1F45190000

22,13 $

Unit Price

GASKET

3C1245120000 3C1245120000

6,45 $

Unit Price

FILTER

3C1E39150000 3C1E39150000

68,18 $

Unit Price

SENDER UNIT ASSY,

B74H57520000 B74H57520000

57,85 $

Unit Price

O-RING

3C1F44860000 3C1F44860000

60,38 $

Unit Price

BRACKET, FUEL PUMP

B74F44250000 B74F44250000

43,35 $

Unit Price

BOLT

913120501000 913120501000

1,00 $

Unit Price

TUBE 1, CARBURANT

B74E39710000 B74E39710000

Not available

HOLDER

B74F419A0000 B74F419A0000

11,87 $

Unit Price

BOLT, FLANGE

950220601200 950220601200

1,00 $

Unit Price

CAP ASSY

B74F46100000 B74F46100000

64,06 $

Unit Price

COVER, FILLER

B74F414A0000 B74F414A0000

42,50 $

Unit Price

PIPE 3

B74F43130000 B74F43130000

36,56 $

Unit Price

ROLL OVER VALVE AS

1DWF41800200 1DWF41800200

131,19 $

Unit Price

CLAMP 1

B74F41350000 B74F41350000

5,73 $

Unit Price

DURITE 4

B74F43140000 B74F43140000

Not available

CANISTER ASSY

B74F41700000 B74F41700000

129,61 $

Unit Price

BAND

B74F483H0000 B74F483H0000

5,22 $

Unit Price

STAY

B74F452E0000 B74F452E0000

10,18 $

Unit Price

STAY 2

B74F454E0000 B74F454E0000

7,46 $

Unit Price

BOLT, FLANGE

950220601200 950220601200

1,00 $

Unit Price

RIVET

902690681600 902690681600

1,02 $

Unit Price

DURITE 5

B74F43150000 B74F43150000

Not available

90467-090A2-00 *

904670900600 904670900600

1,41 $

Unit Price

CLAMP

904641000800 904641000800

3,37 $

Unit Price

DURITE 6

B74F43160000 B74F43160000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
