CYLINDER HEAD FOR YAMAHA R3 2016

CRANKSHAFT / PISTON

Item numbers

2MS-E1102-10-00 *

2MSE11020000 2MSE11020000

2 060,44 $

Unit Price

GUIDE, VALVE 1

2MSE11331000 2MSE11331000

147,54 $

Unit Price

GUIDE, VALVE 1

1WDE11331000 1WDE11331000

83,86 $

Unit Price

FLANGE BOLT

901050602700 901050602700

2,44 $

Unit Price

PLUG, STRAIGHT SCR

903401800200 903401800200

10,67 $

Unit Price

BOLT, FLANGE

950220801200 950220801200

1,82 $

Unit Price

GASKET, O/P UNIT B

904300811900 904300811900

Not available

BOLT, STUD

956120862500 956120862500

4,81 $

Unit Price

BOLT, CYLINDER HOL

2MS113610000 2MS113610000

17,28 $

Unit Price

WASHER, PLATE

902011084500 902011084500

5,19 $

Unit Price

BOLT, HEXAGON SOCK

901100687000 901100687000

10,10 $

Unit Price

NGK-CR8E0-00-00 *

947000087200 947000087200

9,87 $

Unit Price

GASKET, CYLINDER H

2MSE11810000 2MSE11810000

111,67 $

Unit Price

DOWEL PIN

995301401600 995301401600

8,15 $

Unit Price

BOLT

901090689800 901090689800

19,37 $

Unit Price

RUBBER, MOUNT 1

1WDE111G0000 1WDE111G0000

39,16 $

Unit Price

COVER, CYLINDER HE

1WDE11910000 1WDE11910000

316,75 $

Unit Price

1WD-E2241-01-00 *

1WDE22410000 1WDE22410000

23,91 $

Unit Price

GASKET, HEAD COVER

1WDE11930000 1WDE11930000

43,41 $

Unit Price

PLATE

5VY1482K0000 5VY1482K0000

4,95 $

Unit Price

REED VALVE ASSY

1WDE48900000 1WDE48900000

201,87 $

Unit Price

CAP, CASE

1WDE48990000 1WDE48990000

53,12 $

Unit Price

BOLT

913120602000 913120602000

3,84 $

Unit Price

BOLT

901090689900 901090689900

11,50 $

Unit Price

RUBBER, MOUNT 1

1WDE111G0000 1WDE111G0000

39,16 $

Unit Price

CYLINDER 1

2MSE13110000 2MSE13110000

423,78 $

Unit Price

B1X-E1351-00-00 *

1WDE13510000 1WDE13510000

26,78 $

Unit Price

WATER PIPE

5NL125640000 5NL125640000

7,34 $

Unit Price

93210-16772-00 *

932101671600 932101671600

4,68 $

Unit Price

DOWEL PIN

995301401600 995301401600

8,15 $

Unit Price

AIR CUT VALVE ASSY

1WDE48400000 1WDE48400000

373,71 $

Unit Price

HOSE, BEND 1

1WDE48810000 1WDE48810000

9,23 $

Unit Price

90467-16195-00 *

904671680100 904671680100

8,19 $

Unit Price

HOSE, BEND 2

1WDE48820100 1WDE48820100

24,95 $

Unit Price

90467-16195-00 *

904671680100 904671680100

8,19 $

Unit Price

CLIP

904671680000 904671680000

3,92 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
