FUEL TANK FOR YAMAHA XMAX 2022

SEAT

Item numbers

FUEL TANK COMP.

B74F41100100 B74F41100100

Not available

CLAMP(4FM)

904641318500 904641318500

6,67 $

Unit Price

SEAL

BL1F414G0100 BL1F414G0100

Not available

BOLT, WITH WASHER

90119068A200 90119068A200

2,01 $

Unit Price

FUEL PUMP COMP.

B74E39070100 B74E39070100

418,14 $

Unit Price

CLIP

3C1F45190000 3C1F45190000

23,07 $

Unit Price

GASKET

3C1245120000 3C1245120000

6,72 $

Unit Price

FILTER

3C1E39150000 3C1E39150000

71,08 $

Unit Price

SENDER UNIT ASSY,

B74H57520000 B74H57520000

60,31 $

Unit Price

O-RING

3C1F44860000 3C1F44860000

62,95 $

Unit Price

BRACKET, FUEL PUMP 1

B74F44250000 B74F44250000

45,19 $

Unit Price

BOLT

913120501000 913120501000

1,04 $

Unit Price

PIPE, FUEL 1

B74E39710100 B74E39710100

262,72 $

Unit Price

HOLDER

B74F419A0000 B74F419A0000

12,37 $

Unit Price

BOLT, FLANGE

950220601200 950220601200

1,04 $

Unit Price

CAP ASSY

B74F46020000 B74F46020000

Not available

COVER, FILLER

B74F414A0000 B74F414A0000

44,31 $

Unit Price

PIPE 3

B74F43130000 B74F43130000

38,11 $

Unit Price

ROLL OVER VALVE ASSY

1DWF41800200 1DWF41800200

136,77 $

Unit Price

CLAMP 1

B74F41350000 B74F41350000

5,97 $

Unit Price

PIPE 4

B74F43140100 B74F43140100

Not available

CANISTER ASSY

5WYF41700000 5WYF41700000

Not available

STAY

BL1F452E0000 BL1F452E0000

Not available

BOLT

90109068B500 90109068B500

2,50 $

Unit Price

NUT, SPRING

9018306X0300 9018306X0300

Not available

BOLT, FLANGE

950220601200 950220601200

1,04 $

Unit Price

CLIP 101235600

904670800300 904670800300

5,61 $

Unit Price

PIPE 5

BY3F43150000 BY3F43150000

Not available

CLIP

904670900600

90467090A200

1,47 $

Unit Price

CLAMP

904641000800 904641000800

3,51 $

Unit Price

PIPE 6

BL1F43160000 BL1F43160000

Not available

CLIP

9046712X0200 9046712X0200

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FUEL TANK of your Yamaha XMAX 250 of 2022. Let us know if you have any questions.
