LEG SHIELD FOR YAMAHA MAJESTY 1998

IGNITION

PROTEGE-JAMBES COMPLET

4HC283001000 4HC283001000

Not available

COUVERCLE

4HC283651000 4HC283651000

Not available

CHARNIERE

4HC217960000 4HC217960000

Not available

TAPPING SCREW, PANHEAD .2 S

977074051200

977074061200

1,85 $

Unit Price

NUT, SPRING(1YT)

901830504200 901830504200

1,46 $

Unit Price

BOLT, HEXAGON

970070601200

970170601200

2,48 $

Unit Price

WASHER, PLATE (6K8)

902010600800

9020106M0200

4,21 $

Unit Price

SCREW, TAPPING

901670507900 901670507900

2,42 $

Unit Price

SCREW, TAPPING

901670508000 901670508000

2,52 $

Unit Price

AMORTISSEUR

4HC283711100 4HC283711100

Not available

COUVERCLE

4HC2478A2000 4HC2478A2000

Not available

LOCK ASSY 2

4BH217081100 4BH217081100

173,75 $

Unit Price

PANNEAU, FOURCHE NUE 1

4HC2836K1000 4HC2836K1000

Not available

NUT, SPRING(1YT)

901830504200 901830504200

1,46 $

Unit Price

AMORTISSEUR 1

4HC2836T0000 4HC2836T0000

Not available

SCREW, TAPPING

901670507900 901670507900

2,42 $

Unit Price

CORPS, DE CARENAGE

4HC2835101P5 4HC2835101P5

Not available

CORPS, DE CARENAGE

4HC2835101P6 4HC2835101P6

Not available

CORPS, DE CARENAGE

4HC2835101P7 4HC2835101P7

Not available

NUT 1

3VP215350000

25G215350000

5,44 $

Unit Price

NUT, SPRING(1YT)

901830504200 901830504200

1,46 $

Unit Price

NUT(1KT)

901790552300 901790552300

8,74 $

Unit Price

BOLT, WITH WASHER

901190606000

901190622600

1,39 $

Unit Price

BOLT(3KJ)

90109063F100 90109063F100

4,46 $

Unit Price

SCREW, TAPPING

901670508000 901670508000

2,52 $

Unit Price

SCREW, TAPPING(3VP)

901630500600 901630500600

2,91 $

Unit Price

PANNEAU, FOURCHE NUE 2

4HC2836L1000 4HC2836L1000

Not available

SCREW, TAPPING

901670507900 901670507900

2,42 $

Unit Price

SCREW, TAPPING

901670507900 901670507900

2,42 $

Unit Price

PARE-BRISE

5CG2837U0000 5CG2837U0000

Not available

MOULURE

4EJ283760000 4EJ283760000

Not available

SCREW, ROUND HEAD(1UX)

901500502400 901500502400

4,57 $

Unit Price

MOULURE 1

4HC28345007B 4HC28345007B

Not available

NUT, SPRING(1YT)

901830504200 901830504200

1,46 $

Unit Price

MOLE 3

1NL283470100 1NL283470100

7,05 $

Unit Price

SCREW, TAPPING

901670507900 901670507900

2,42 $

Unit Price

COUVERCLE

4HC28385A0P6 4HC28385A0P6

Not available

COUVERCLE

4HC28385A0P7 4HC28385A0P7

Not available

COUVERCLE

4HC28385A0P8 4HC28385A0P8

Not available

NUT, SPRING(1YT)

901830504200 901830504200

1,46 $

Unit Price

EMBLEME

4HC283150000 4HC283150000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the LEG SHIELD of your Yamaha YP250D of 1998. Let us know if you have any questions.
