REAR FENDER

SWINGARM FOR YAMAHA RAPTOR 2011

REAR SHOCK ABSORBER

Item numbers

REAR ARM

4D32211000P0 4D32211000P0

955,36 $

Unit Price

PIECE ROULEMENT

933172223700 933172223700

Not available

OIL SEAL 35X41.5X8

931083500400 931083500400

16,94 $

Unit Price

COVER

30X2219X0000 30X2219X0000

17,82 $

Unit Price

BUSH

4D3221840000 4D3221840000

67,10 $

Unit Price

GUARD SEAL

4D3221510000 4D3221510000

25,42 $

Unit Price

BOLT

901090617200 901090617200

2,09 $

Unit Price

PIVOT SHAFT

2JN221410000 2JN221410000

65,80 $

Unit Price

WASHER, PLATE

902011402000 902011402000

3,93 $

Unit Price

NUT, SELF-LOCKING

901851400900 901851400900

13,55 $

Unit Price

91314-08060-00 *

913120806000 913120806000

10,19 $

Unit Price

NUT, PJTN.

4D3223140000 4D3223140000

12,89 $

Unit Price

PLATE 2

4D3223480000 4D3223480000

4,38 $

Unit Price

DUST COVER

4D32217H0000 4D32217H0000

11,50 $

Unit Price

COVER

4D32219X0000 4D32219X0000

50,43 $

Unit Price

CHAIN CASE PLATE

4D3223470000 4D3223470000

15,25 $

Unit Price

BOLT

901090623600 901090623600

2,42 $

Unit Price

HUB, REAR

2PA253110000 2PA253110000

426,57 $

Unit Price

BEARING

933060071000 933060071000

43,94 $

Unit Price

OIL SEAL

931064600100 931064600100

17,69 $

Unit Price

BEARING SPACER

4D3253170000 4D3253170000

37,25 $

Unit Price

CALIPER BRACKET

4D3257210000 4D3257210000

131,19 $

Unit Price

CIRCLIP

934106708500 934106708500

14,59 $

Unit Price

WHEEL COLLAR

4D3253770000 4D3253770000

15,60 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the SWINGARM of your Yamaha YFM250R of 2011. Let us know if you have any questions.
