HANDLE SWITCH / LEVER

ELECTRICAL 1 FOR YAMAHA WRF 2004

ALTERNATIVE CHASSIS

BLOC C.D.I.

5UM855405000 5UM855405000

Not available

BLOC C.D.I.

5UM855406000 5UM855406000

Not available

BAND

5TJ855460000 5TJ855460000

14,04 $

Unit Price

IGNITION COIL ASSY

5UL823101000 5UL823101000

212,09 $

Unit Price

NEUTRAL SWITCH ASS

5TJ825400100 5TJ825400100

137,88 $

Unit Price

93210-21001-00 *

932102127600 932102127600

2,92 $

Unit Price

98907-05016-00 *

901540502600 901540502600

2,01 $

Unit Price

CLAMP (81E)

904641307700 904641307700

5,38 $

Unit Price

90464-15152-00 *

904651327500 904651327500

5,69 $

Unit Price

90464-15195-00 *

904641307300 904641307300

4,73 $

Unit Price

CLAMP (4FM)

904641519500 904641519500

4,73 $

Unit Price

1UA-82591-00-00 *

904651315200 904651315200

2,98 $

Unit Price

CLAMP 1

5Y9124910000 5Y9124910000

1,99 $

Unit Price

90464-25267-00 *

904642304100 904642304100

2,45 $

Unit Price

FAISCEAU DE FILS COMPLET

5TJ825906000 5TJ825906000

Not available

DIODE ASSY

5TJ819800000 5TJ819800000

20,45 $

Unit Price

DIODE ASSY

4WA819800000 4WA819800000

30,66 $

Unit Price

RECTIFIER & REGULA

5TJ819600200 5TJ819600200

251,86 $

Unit Price

BOLT, FLANGE (6U1)

950270602000 950270602000

2,36 $

Unit Price

5TJ-2128A-01-00 *

5TJ2128A0000 5TJ2128A0000

Not available

BOLT, FLANGE (4MY)

950270601000 950270601000

2,01 $

Unit Price

CLAMP

904642922300 904642922300

5,62 $

Unit Price

5TJ-82100-00-00 *

5UM821000900 5UM821000900

234,52 $

Unit Price

BATTERY BAND

8CY821310000 8CY821310000

14,30 $

Unit Price

WIRE PLUS LEAD

5TJ821150000 5TJ821150000

22,72 $

Unit Price

FIL, NEGATIF

5UM821160000 5UM821160000

Not available

5TJ-81940-11-00 *

5TJ819401000 5TJ819401000

96,88 $

Unit Price

FUSE, 10A

42X821510000 42X821510000

3,45 $

Unit Price

WIRE LEAD COVER

5SL821191000 5SL821191000

6,39 $

Unit Price

BOLT, SMALL FLANGE

950270600800 950270600800

2,01 $

Unit Price

SUPPORT, RELAIS

5TJ819520000 5TJ819520000

Not available

RELAY ASSY

8DM819500000 8DM819500000

48,28 $

Unit Price

CONTACTEUR A CLEF COMPLET

5TJ825100000 5TJ825100000

Not available

MAIN SWITCH STAY

5TJ825140000 5TJ825140000

22,90 $

Unit Price

90464-76001-00 *

904645025500 904645025500

6,86 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the ELECTRICAL 1 of your Yamaha WR250F of 2004. Let us know if you have any questions.
