SWINGARM FOR YAMAHA WRZ 1998

REAR SHOCK ABSORBER

BRAS ARRIERE COMP.

5EN221100000 5EN221100000

Not available

SCREW, FLAT

901510404800

987070401000

2,01 $

Unit Price

PASTILLE

4SS223550000 4SS223550000

Not available

BEARING, CYLINDRICAL(2VM)

933172226200 933172226200

30,97 $

Unit Price

PLUG(55K)

903381614800 903381614800

14,48 $

Unit Price

OIL SEAL (23X)

931062201900 931062201900

13,44 $

Unit Price

BEARING, THRUST(4EW)

933422221500 933422221500

45,74 $

Unit Price

COUVERCLE, BUTEE 2

5DH221290000 5DH221290000

Not available

COLLERETTE

903871712R00 903871712R00

Not available

SHIM

156221270000 156221270000

2,68 $

Unit Price

SEAL, GUARD

4EW221512000 4EW221512000

84,34 $

Unit Price

BOLT, HEX. SOCKET BUTTON

901100520100

901110505900

4,89 $

Unit Price

SUPPORT, CHAINE

4MX221990000 4MX221990000

Not available

COVER, THRUST 1

4XM221280000 4XM221280000

85,53 $

Unit Price

BOLT, SMALL FLANGE

950270605000 950270605000

2,42 $

Unit Price

NUT, FLANGE(7NB)

901790656800

957040650000

3,05 $

Unit Price

BOLT, FLANGE(4MY)

950270601000 950270601000

2,01 $

Unit Price

SHAFT, PIVOT

5DH221410000 5DH221410000

102,60 $

Unit Price

NUT, SELF-LOCKING

901851612700

901851600200

20,44 $

Unit Price

WASHER, PLATE(33Y)

90201164H400 90201164H400

8,84 $

Unit Price

BRAS DE LIAISON

5DH2217A0000 5DH2217A0000

Not available

BEARING, CYLINDRICAL(4BF)

933153205600 933153205600

30,76 $

Unit Price

OIL SEAL

931092002900

931092007600

16,93 $

Unit Price

COLLAR(1LV)

90387164N200 90387164N200

25,33 $

Unit Price

COLLERETTE

90387164N300 90387164N300

Not available

COLLAR(4EW)

90387167Y900 90387167Y900

19,73 $

Unit Price

BOULON

90109147F200 90109147F200

Not available

BOLT (3JE)

90109142F400 90109142F400

33,15 $

Unit Price

WASHER, PLATE(33Y)

90201164H400 90201164H400

8,84 $

Unit Price

WASHER PLATE (3L6)

902011474000 902011474000

5,38 $

Unit Price

NUT, SELF-LOCKING

901851411200 901851411200

13,94 $

Unit Price

CONNECTING ROD 1

5DH2217F0000

5DH2217F0100

270,56 $

Unit Price

BEARING, CYLINDRICAL(4BF)

933153205600 933153205600

30,76 $

Unit Price

OIL SEAL

931092002900

931092007600

16,93 $

Unit Price

COVER

1HX2135F1000 1HX2135F1000

14,98 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the SWINGARM of your Yamaha WR250Z of 1998. Let us know if you have any questions.
