CAMSHAFT / TIMING CHAIN

OIL PUMP FOR YAMAHA SR 1996

INTAKE

OIL PUMP ASSY

3Y6133000100 3Y6133000100

167,24 $

Unit Price

3Y6-13326-10-00 *

3Y6133260100 3Y6133260100

19,65 $

Unit Price

DOWEL PIN (137)

936031203000 936031203000

2,48 $

Unit Price

O-RING (611)

932101009600 932101009600

3,50 $

Unit Price

98517-06025-00 *

985070602500 985070602500

2,01 $

Unit Price

GASKET

904300615600 904300615600

3,99 $

Unit Price

IDLE GEAR, OIL PUM

3Y1133410000 3Y1133410000

31,03 $

Unit Price

WASHER, PLAIN735

902011011900 902011011900

6,20 $

Unit Price

CIRCLIP (10W)

990091040000 990091040000

1,57 $

Unit Price

2XK-13416-00-00 *

3Y1134160100 3Y1134160100

3,96 $

Unit Price

STRAINER, OIL

51Y134110000 51Y134110000

10,91 $

Unit Price

SPRING, COMPRESSIO

905011857600 905011857600

2,47 $

Unit Price

DRAIN PLUG

3Y1153510100 3Y1153510100

17,63 $

Unit Price

JOINT TORIQUE

932101035100 932101035100

Not available

4X7-13440-90-00 *

4X7134400100 4X7134400100

Not available

JOINT TORIQUE

932103429700 932103429700

Not available

O-RING, OIL DRAIN

932100713500 932100713500

5,47 $

Unit Price

OIL FILTER COVER

2J2134470000 2J2134470000

21,93 $

Unit Price

BOLT, OIL DRAIN

901090641900 901090641900

8,84 $

Unit Price

PAN HEAD SCREW

985070609000 985070609000

2,54 $

Unit Price

GASKET (583)

904300512600 904300512600

7,13 $

Unit Price

SCREW (583)

901490511000 901490511000

2,50 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the OIL PUMP of your Yamaha SR250 of 1996. Let us know if you have any questions.
