SWITCH / LEVER

ELECTRICAL 1 FOR YAMAHA TTR 2006

IGNITION COIL ASSY

3NS823101000

3KJ823101300

60,54 $

Unit Price

BOLT, FLANGE

9502M0601600

958170601600

3,30 $

Unit Price

PLUG CAP ASSY

3NS823700000 3NS823700000

44,45 $

Unit Price

NEUTRAL SWITCH ASSY

4GY825401000 4GY825401000

30,06 $

Unit Price

GASKET (1KH, 1.0T)

904301014800 904301014800

6,35 $

Unit Price

RECTIFIER & REGULATOR ASSY

5HHH19600000

4CK819600100

222,19 $

Unit Price

BOLT, FLANGE(4MY)

9502M0601200

950270601200

2,10 $

Unit Price

YTX5LBS YUASA BATTERY - SA

1C6H21100000

YTX5LBS00000

101,86 $

Unit Price

WIRE PLUS LEAD

1C6H21150000 1C6H21150000

82,94 $

Unit Price

MINUS WIRE LEAD

1C6H21160000 1C6H21160000

82,96 $

Unit Price

BAND, BATTERY

1C6H21310000 1C6H21310000

19,16 $

Unit Price

MAIN SWITCH ASSY

1C6825100000

1C6825100100

227,48 $

Unit Price

WIRE HARNESS ASSY

1C6H25900000 1C6H25900000

374,34 $

Unit Price

CLAMP(MF1)

904651327500

904641515200

5,93 $

Unit Price

BAND

904651315200

1UA825910000

3,11 $

Unit Price

CLAMP

904641307700 904641307700

5,61 $

Unit Price

STARTER RELAY ASSY (RC19-028)

5HH819400200 5HH819400200

108,61 $

Unit Price

FUSE (10A)

42X821510000 42X821510000

3,60 $

Unit Price

BOLT, SMALL FLANGE

9502M0600800

950270600800

2,10 $

Unit Price

C.D.I. UNIT ASSY

1C6H55400000 1C6H55400000

846,59 $

Unit Price

BAND

1C6H55460000 1C6H55460000

18,46 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the ELECTRICAL 1 of your Yamaha TT-R230 of 2006. Let us know if you have any questions.
