SIDE COVER FOR YAMAHA XT 1993

SWINGARM

Item numbers

COVER, SIDE 1

3RW217111000 3RW217111000

Not available

GRAPHIC 1

3RW2173L1100 3RW2173L1100

Not available

GRAPHIC 1

3RW2173L3100 3RW2173L3100

Not available

GROMMET (41Y)

904800140100 904800140100

4,72 $

Unit Price

SCREW (1KH)

901490622300 901490622300

6,67 $

Unit Price

90387-06107-00 *

90387064J100 90387064J100

8,85 $

Unit Price

GROMMET (41Y)

904800140100 904800140100

4,72 $

Unit Price

PLATE

4U52176E0000 4U52176E0000

7,87 $

Unit Price

COVER, SIDE 2

3RW217211000 3RW217211000

Not available

GRAPHIC 2

3RW2174L1000 3RW2174L1000

Not available

GRAPHIC 2

3RW2174L3000 3RW2174L3000

Not available

SCREW (1KH)

901490622300 901490622300

6,67 $

Unit Price

90387-06107-00 *

90387064J100 90387064J100

8,85 $

Unit Price

PLATE

4U52176E0000 4U52176E0000

7,87 $

Unit Price

GROMMET (2H7)

904801122400 904801122400

3,87 $

Unit Price

GROMMET (41Y)

904800140100 904800140100

4,72 $

Unit Price

3RW-2177A-02-00 *

3RW2177A0100 3RW2177A0100

Not available

SEAL 3

3RW2173M0000 3RW2173M0000

Not available

95817-06016-00 *

958110601600 958110601600

3,17 $

Unit Price

COLLAR

903870650000 903870650000

8,84 $

Unit Price

90119-06117-00 *

901190604200 901190604200

4,13 $

Unit Price

COVER

3RW2177F0000 3RW2177F0000

Not available

PLATE, EPA 1 (CALIFORNIA)

4BE2179N1000 4BE2179N1000

Not available

PLATE, EPA 1 (NON CALIFORNIA)

4BE2179V1000 4BE2179V1000

Not available

TOOL KIT

3RW281000100 3RW281000100

Not available

55V-28173-01-00 *

55V281730000 55V281730000

36,90 $

Unit Price

LID

55V281850000 55V281850000

21,42 $

Unit Price

DAMPER 5

3RW282670000 3RW282670000

Not available

BOLT WITH WASHER

901190610800 901190610800

3,99 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the SIDE COVER of your Yamaha XT225 of 1993. Let us know if you have any questions.
