INTAKE

CARBURETOR FOR YAMAHA TW 2024

EXHAUST

Item numbers

CARBURETOR ASSY 1

5FY143011000 5FY143011000

790,44 $

Unit Price

SCREW, PAN HEAD(62X)

978010501000

978850501000

4,00 $

Unit Price

SCREW, THROTTLE

5LB143210000 5LB143210000

146,08 $

Unit Price

SPRING, THROTTLE STOP

2JX143330000 2JX143330000

3,47 $

Unit Price

WASHER, PLAIN

5LB143570000 5LB143570000

2,14 $

Unit Price

SUCTION PISTON ASSY

5LB1434A0000 5LB1434A0000

100,24 $

Unit Price

SEAT, SPRING

5LB149360000 5LB149360000

23,69 $

Unit Price

SPRING

5LB142750000 5LB142750000

2,16 $

Unit Price

NEEDLE

5FY143360000 5FY143360000

30,88 $

Unit Price

SPRING

5LB142860000 5LB142860000

12,72 $

Unit Price

SCREW

5LB142160000 5LB142160000

2,51 $

Unit Price

NOZZLE, MAIN

5LB143410000 5LB143410000

41,67 $

Unit Price

BLEED, MAIN NOZZLE

5LB143411000 5LB143411000

41,67 $

Unit Price

JET, MAIN (#126)

5FY143436300 5FY143436300

25,18 $

Unit Price

JET, PILOT (#31)

5LB143426500 5LB143426500

23,47 $

Unit Price

PILOT SCREW SET

5LB141050000 5LB141050000

17,34 $

Unit Price

DIAPHRAGM ASSY 1

5LB143680000 5LB143680000

74,06 $

Unit Price

SPRING

5LB145890000 5LB145890000

6,84 $

Unit Price

COVER 1

5LB142930000 5LB142930000

26,30 $

Unit Price

SCREW, LEVER FITTING

214245350000 214245350000

5,02 $

Unit Price

PLUG

50M143550000

50M143550100

10,59 $

Unit Price

PLUNGER, STARTER

5FY143710000 5FY143710000

117,36 $

Unit Price

FLOAT

5LB143850000 5LB143850000

74,24 $

Unit Price

PIN, FLOAT

5LB143860000 5LB143860000

4,61 $

Unit Price

NEEDLE VALVE ASSY

5LB143900000 5LB143900000

39,01 $

Unit Price

GASKET, FLOAT CHAMBER

5LB143840000 5LB143840000

19,94 $

Unit Price

AIR SCREW SET

4JP143230000

4JP141040000

11,92 $

Unit Price

SCREW

5LB145920000 5LB145920000

2,05 $

Unit Price

BRACKET 2

5LB142920000 5LB142920000

8,58 $

Unit Price

5FY141970000

5LB141970000

15,18 $

Unit Price

PIPE

5FY141960000 5FY141960000

16,73 $

Unit Price

PLUG

4KN1432A0000 4KN1432A0000

3,83 $

Unit Price

SCREW, BIND(6L2)

989010400600

989800400600

3,48 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CARBURETOR of your Yamaha TW 200 of 2024. Let us know if you have any questions.
