HANDLEBAR & CABLES

STAND / FOOTREST FOR YAMAHA AG 1993

IGNITION

Item numbers

PEDALE, FREIN

36X272110090 36X272110090

Not available

BOLT (4MY)

970010602000

970070602000

2,42 $

Unit Price

NUT(650)

953030670000

953800670000

4,53 $

Unit Price

TIGE DE FREIN

36X272310000 36X272310000

Not available

PIN, CLEVIS (24X)

902400604000

902400610300

6,00 $

Unit Price

YBS66-6 WASHER, PLAIN

929010620000

929900620000

1,68 $

Unit Price

COTTER PIN

914012001500

914012002000

3,75 $

Unit Price

SPRING, TENSION (36X)

905061434300 905061434300

5,40 $

Unit Price

SPRING, (180-27236-00)

905011024500 905011024500

4,23 $

Unit Price

PIN 1562723700

902491200800 902491200800

5,17 $

Unit Price

NUT, WING (1K5)

901750601300 901750601300

4,26 $

Unit Price

REPOSE-PIEDS AV (G)

36X274100090 36X274100090

Not available

SPRING, TORSION (214-27426-00)

905082002300 905082002300

7,77 $

Unit Price

PIN, CLEVIS (2A6)

917010803800 917010803800

3,93 $

Unit Price

PIN, COTTER

914012501500

914902502000

3,93 $

Unit Price

REPOSE-PIEDS AV (D)

36X274200090 36X274200090

Not available

SPRING, TORSION (214-27426-00)

905082002300 905082002300

7,77 $

Unit Price

PIN, CLEVIS (2A6)

917010803800 917010803800

3,93 $

Unit Price

PIN, COTTER

914012501500

914902502000

3,93 $

Unit Price

BOLT, FLANGE

958211202500

958171202500

7,08 $

Unit Price

BOLT, HEXAGON (447)

901051005800 901051005800

6,00 $

Unit Price

BEQUILLE, LATERALE

36X2731100R4 36X2731100R4

Not available

BEQUILLE, LATERALE

36X2731110R4 36X2731110R4

Not available

SPRING, TENSION (1L9)

905062627000 905062627000

19,14 $

Unit Price

BOLT

90109103A100

901091047300

4,69 $

Unit Price

NUT, U

901851003700 901851003700

9,07 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the STAND / FOOTREST of your Yamaha AG200E of 1993. Let us know if you have any questions.
