SADDLEBAG

SADDLEBAG 2 FOR YAMAHA STAR VENTURE 2020

TOP CASE

Item numbers

FRAME, SADDLEBAG 2

2DF284740000 2DF284740000

306,81 $

Unit Price

BOLT, FLANGE DEEP RECESS

95D320804500 95D320804500

1,60 $

Unit Price

BOLT, FLANGE(8AB)

958170802000 958170802000

3,47 $

Unit Price

STAY, FRONT GUARD 2

2DF284140000 2DF284140000

59,31 $

Unit Price

BOLT, WASHER BASED(JA9)

950270601600

901050669600

7,86 $

Unit Price

COVER, SIDE BOX 2

2DF2846U0000 2DF2846U0000

130,40 $

Unit Price

PATCH

2DF284580000 2DF284580000

12,49 $

Unit Price

BOLT, FLANGE

950220601200 950220601200

1,04 $

Unit Price

COLLAR

903870607100 903870607100

10,24 $

Unit Price

DAMPER 8

2DF2847N0000 2DF2847N0000

8,98 $

Unit Price

DAMPER, PLATE

905201003200 905201003200

6,37 $

Unit Price

DAMPER 11

2DF2847S0000 2DF2847S0000

6,64 $

Unit Price

PLATE, BOTTOM 2

2DF2841T0000 2DF2841T0000

35,40 $

Unit Price

SADDLEBAG ASSY., 2

2DF2842004P0

2DF2842007P0

5 442,89 $

Unit Price

HOOK 3

2DF284940000 2DF284940000

187,78 $

Unit Price

BOLT, BUTTON HEAD

920170601400 920170601400

4,00 $

Unit Price

WASHER, PLATE

902010605500 902010605500

3,94 $

Unit Price

COVER 4

2DF2844J0000

2DF2844J0100

56,65 $

Unit Price

NUT, SPRING(4TV)

901830507300 901830507300

9,23 $

Unit Price

BOLT, HEX. SOCKET BUTTON

901110502100 901110502100

Not available

DAMPER 1

2DF284150000 2DF284150000

9,29 $

Unit Price

SEAL 5

2DF2847F0000 2DF2847F0000

10,33 $

Unit Price

PLUG (17J)

903381013200 903381013200

3,20 $

Unit Price

SEAL 4

2DF2846F0000 2DF2846F0000

5,73 $

Unit Price

STAY, 7

2DF284BF0000 2DF284BF0000

46,00 $

Unit Price

SADDLEBAG 4

2DF2844900P0 2DF2844900P0

523,72 $

Unit Price

NUT, SPRING

90183062A000 90183062A000

6,02 $

Unit Price

SEAL 2

2DF284290000 2DF284290000

89,08 $

Unit Price

CLAMP

2DF811280000 2DF811280000

6,64 $

Unit Price

STAY, 10

2DF284BH0000 2DF284BH0000

55,38 $

Unit Price

SEAL, 16

2DF284BP0000 2DF284BP0000

4,31 $

Unit Price

HINGE SUB-ASSY., 2

2DF2844S0000

2DF2844S0100

1 023,68 $

Unit Price

BOLT, HEX. SOCKET BUTTON

901110610200

901110610300

1,46 $

Unit Price

BRACKET, HINGE 2

2DF2846N0000 2DF2846N0000

41,24 $

Unit Price

WASHER, PLATE

902010655700 902010655700

5,53 $

Unit Price

REAR REFLECTOR ASSY

2DF851300000 2DF851300000

88,97 $

Unit Price

COVER, HINGE 2

2DF2846L0000 2DF2846L0000

356,74 $

Unit Price

BOLT, BUTTON HEAD

920170601000 920170601000

4,00 $

Unit Price

REAR FLASHER LIGHT ASSY 2

2DF833400000 2DF833400000

531,91 $

Unit Price

SCREW, TAPPING(4MV)

977075001600 977075001600

2,15 $

Unit Price

GARNISH, FLASHER 2

2DF833A20000 2DF833A20000

269,93 $

Unit Price

SCREW, BINDING

989070501200 989070501200

2,10 $

Unit Price

SCREW, TAPPING(4MV)

977075001600 977075001600

2,15 $

Unit Price

LID 2

2DF2844C0000 2DF2844C0000

102,21 $

Unit Price

SCREW, TAPPING(4MV)

977075001600 977075001600

2,15 $

Unit Price

WASHER PLATE 122217250000

902020701500 902020701500

3,06 $

Unit Price

SWITCH

2DF826170000 2DF826170000

93,89 $

Unit Price

BRACKET 3

2DF284760000 2DF284760000

33,07 $

Unit Price

SCREW, TAPPING(4MV)

977075001600 977075001600

2,15 $

Unit Price

WIRE, LEAD 8

2DF861780100 2DF861780100

145,97 $

Unit Price

BAND, TOOL

2DF213760000 2DF213760000

24,34 $

Unit Price

SCREW, TRUSS TAP.

977025001400

977075001400

2,10 $

Unit Price

CAP, 2

2DF2845X0000 2DF2845X0000

52,70 $

Unit Price

CLAMP

904642600100 904642600100

2,48 $

Unit Price

LOCK ASSY

2DFW28491000

2DFW28491100

596,14 $

Unit Price

BOLT

901110604100 901110604100

4,93 $

Unit Price

HANGER, HELMET

2DF213980000 2DF213980000

30,27 $

Unit Price

WASHER (23T)

90201065G800 90201065G800

5,56 $

Unit Price

GROMMET(1NL)

904802044700 904802044700

8,37 $

Unit Price

COLLAR

903870811100 903870811100

5,29 $

Unit Price

BOLT, BUTTON

920170603500 920170603500

4,03 $

Unit Price

PLATE, 13

2DF2849X0000 2DF2849X0000

27,73 $

Unit Price

BOLT, FLANGE

950220601200 950220601200

1,04 $

Unit Price

BAND, 1

2DF2846G0000 2DF2846G0000

43,38 $

Unit Price

STAY, SIDE BAG

2DF284230000 2DF284230000

181,25 $

Unit Price

PLUG

903380701000 903380701000

4,22 $

Unit Price

BOLT, FLANGE DEEP RECESS

95D370601400 95D370601400

0,65 $

Unit Price

TOOL KIT

2DF281000000 2DF281000000

22,96 $

Unit Price

LABEL, CAUTION

4XY284460200 4XY284460200

15,96 $

Unit Price

CAUTION LABEL

4XY284461200 4XY284461200

29,05 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the SADDLEBAG 2 of your Yamaha STAR VENTURE TC of 2020. Let us know if you have any questions.
