JET UNIT 4

GENERATOR FOR YAMAHA FX 2024

STARTING MOTOR

Item numbers

STARTER ONE-WAY AS

6S5155900000 6S5155900000

540,66 $

Unit Price

91317-08020-00 *

901100821200 901100821200

5,04 $

Unit Price

GEAR 3

6LE155150000 6LE155150000

550,21 $

Unit Price

SHAFT 1

6S5155210000 6S5155210000

18,37 $

Unit Price

IDLER GEAR 2

6S5155170000 6S5155170000

276,82 $

Unit Price

ROTOR ASSY

6S5814500100 6S5814500100

821,76 $

Unit Price

STATOR ASSY

6ET814100000 6ET814100000

503,98 $

Unit Price

90149-06182-00 *

901490622900 901490622900

2,08 $

Unit Price

BOLT, WITH WASHER

975130551400 975130551400

3,44 $

Unit Price

WOODRUFF KEY 1WG

902800304700 902800304700

7,45 $

Unit Price

COVER, FLYWHEEL

6S5813373100 6S5813373100

631,18 $

Unit Price

BEARING

933060080900 933060080900

118,92 $

Unit Price

OIL SEAL

6LE811670000 6LE811670000

60,35 $

Unit Price

93420-72065-00 *

990097250000 990097250000

11,50 $

Unit Price

BOLT, FLANGE

901050824900 901050824900

5,31 $

Unit Price

DOWEL PIN

995301011400 995301011400

3,55 $

Unit Price

O-RING

6S5811680000 6S5811680000

64,13 $

Unit Price

CLAMP

6S5813280000 6S5813280000

15,40 $

Unit Price

BOLT (4MY)

913170601400 913170601400

4,05 $

Unit Price

BOLT, SOCKET

913170501000 913170501000

2,51 $

Unit Price

WASHER, PLATE 7N7

90201052E800 90201052E800

3,16 $

Unit Price

COLLAR (6H4)

9038706M0500 9038706M0500

8,85 $

Unit Price

BOLT

913800602000 913800602000

3,54 $

Unit Price

GROMMET

6S5813641100 6S5813641100

12,89 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the GENERATOR of your Yamaha FX CRUISER SVHO of 2024. Let us know if you have any questions.
