SEAT / LOCK FOR YAMAHA FX 2024

SEAT / LOCK 2

Item numbers

DOUBLE SEAT ASSY

F3XU371AY000 F3XU371AY000

975,35 $

Unit Price

COVER, SEAT 1

F3XU371BY000 F3XU371BY000

750,61 $

Unit Price

PACKING

F3XU26640100 F3XU26640100

128,29 $

Unit Price

SEAT LOCK ASSY

F2CU38500000 F2CU38500000

42,52 $

Unit Price

90119-06914-00 *

90119069UP00 90119069UP00

4,04 $

Unit Price

SINGLE SEAT ASSY

F3XU372AY000 F3XU372AY000

508,87 $

Unit Price

COVER, SEAT

F3XU372BY000 F3XU372BY000

308,86 $

Unit Price

PACKING 5

F3XU266D0100 F3XU266D0100

170,61 $

Unit Price

SEAT LOCK ASSY

F2CU38500000 F2CU38500000

42,52 $

Unit Price

90119-06914-00 *

90119069UP00 90119069UP00

4,04 $

Unit Price

DECK BEAM ASSY

F2SU890L0500 F2SU890L0500

93,14 $

Unit Price

GH1U37740000 GH1U37740000

34,18 $

Unit Price

WASHER, PLATE

90201109U600 90201109U600

7,78 $

Unit Price

WASHER

9299R1020000 9299R1020000

3,52 $

Unit Price

FLANGE NUT

9572R1030000 9572R1030000

8,38 $

Unit Price

PACKING 1

F2SU375E0000 F2SU375E0000

7,86 $

Unit Price

PACKING

F2SU82440000 F2SU82440000

2,08 $

Unit Price

BOLT WITH WASHER

901190882800 901190882800

3,41 $

Unit Price

NUT, LOCK

F3YU142L0000 F3YU142L0000

7,68 $

Unit Price

CASE ASSY 1

F2CU591A0300 F2CU591A0300

93,33 $

Unit Price

CASE CAP

F2CU591C0000 F2CU591C0000

12,39 $

Unit Price

PACKING, CASE

F2CU591D0100 F2CU591D0100

4,56 $

Unit Price

PACKING, 6

F2CU266E0000 F2CU266E0000

24,08 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the SEAT / LOCK of your Yamaha FX LIMITED SVHO of 2024. Let us know if you have any questions.
