STARTER CLUTCH

STARTER CLUTCH FOR YAMAHA VMAX 2020

TRANSMISSION

Item numbers

PRIMARY DRIVEN GEA

2S3161500000 2S3161500000

1 056,74 $

Unit Price

PUMP DRIVE GEAR

2S3133240000 2S3133240000

179,72 $

Unit Price

DOWEL PIN (409)

936041609200 936041609200

3,29 $

Unit Price

CIRCLIP (682)

9344057M0100 9344057M0100

15,40 $

Unit Price

THRUST PLATE

4B1161540000 4B1161540000

208,33 $

Unit Price

WASHER, CONICAL SP

902082500200 902082500200

13,86 $

Unit Price

PRESSURE PLATE ASS

2S3163600000 2S3163600000

757,81 $

Unit Price

CLUTCH BOSS ASSY

2S3163700000 2S3163700000

646,85 $

Unit Price

2H7-16325-10-00 *

2H7163250000 2H7163250000

22,39 $

Unit Price

FRICTION PLATE

5YU163210000 5YU163210000

28,50 $

Unit Price

PRESSURE PLATE 1

2S3163510000 2S3163510000

137,61 $

Unit Price

93306-00315-00 *

933060030400 933060030400

31,31 $

Unit Price

CLUTCH SPRING 2

5YU163340000 5YU163340000

133,79 $

Unit Price

SPRING HOUSING

36Y163350000 36Y163350000

19,28 $

Unit Price

PLATE, PRESSURE 3

2S3163530000 2S3163530000

15,53 $

Unit Price

97017-06025-00 *

970020602500 970020602500

2,32 $

Unit Price

2S3-16539-01-00 *

2S3165390000 2S3165390000

29,74 $

Unit Price

2H7-16324-10-00 *

2H7163240000 2H7163240000

24,69 $

Unit Price

2H7-16325-10-00 *

2H7163250000 2H7163250000

22,39 $

Unit Price

2H7-16324-10-00 *

2H7163240000 2H7163240000

24,69 $

Unit Price

2H7-16325-10-00 *

2H7163250000 2H7163250000

22,39 $

Unit Price

47X-16324-10-00 *

47X163240000 47X163240000

33,05 $

Unit Price

THRUST PLATE 2

5VY161640000 5VY161640000

22,59 $

Unit Price

COLLAR

903872502600 903872502600

42,06 $

Unit Price

BEARING

933103355900 933103355900

33,48 $

Unit Price

NUT LOCK

2S3163770000 2S3163770000

86,54 $

Unit Price

PUSH ROD 1

4KG163560000 4KG163560000

22,35 $

Unit Price

O-RING

932100663200 932100663200

6,36 $

Unit Price

93511-32027-00 *

935113201700 935113201700

4,96 $

Unit Price

PUSH ROD 2

2S3163570000 2S3163570000

73,24 $

Unit Price

OIL SEAL

931020800800 931020800800

14,08 $

Unit Price

PUSH LEVER COMP.

2S3163810000 2S3163810000

242,31 $

Unit Price

CUP

2S31638G0000 2S31638G0000

14,85 $

Unit Price

BOOT

2S31638J0000 2S31638J0000

29,18 $

Unit Price

91312-06030-00 *

901100624600 901100624600

5,37 $

Unit Price

DOWEL PIN (6G8)

995300801200 995300801200

3,32 $

Unit Price

KICK SHAFT SHIM

2S3156450000 2S3156450000

26,96 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the STARTER CLUTCH of your Yamaha VMAX 1700 of 2020. Let us know if you have any questions.
