FUEL TANK

SEAT FOR YAMAHA ROADSTAR WARRIOR 2004

FRONT WHEEL

SINGLE SEAT ASSY

5PX247100000 5PX247100000

657,31 $

Unit Price

REAR STAY

5PX247190000 5PX247190000

9,83 $

Unit Price

95604-06200-00 *

956070620000 956070620000

4,12 $

Unit Price

SEAT PAD

22W247410000 22W247410000

8,19 $

Unit Price

.SILENT-BLOC DE SELLE SILENT-BLOC DE SELLE

5PX247230100 5PX247230100

Not available

SEAT LOCK ASSY

4BP247800000 4BP247800000

61,11 $

Unit Price

PLATE

4BP247920000 4BP247920000

5,86 $

Unit Price

NUT, FLANGE (4MV)

957070650000 957070650000

2,01 $

Unit Price

CABLE, SEAT LOCK

5PX2478E0000 5PX2478E0000

22,45 $

Unit Price

SUPPORT

5PX2475N1000 5PX2475N1000

Not available

BOLT, SMALL FLANGE

950270801600 950270801600

3,84 $

Unit Price

TANDEM SEAT ASSY

5PX247500000 5PX247500000

351,76 $

Unit Price

.COUVRE, SELLE COUVRE, SELLE

5PX2470F2000 5PX2470F2000

Not available

.SUPPORT, LEVIER DE SELLE 2 SUPPORT, LEVIER DE SELLE 2

5PX2475J0000 5PX2475J0000

Not available

.BANDE DE SELLE BANDE DE SELLE

5PX247340000 5PX247340000

Not available

DAMPER, SEAT

509247240000 509247240000

5,37 $

Unit Price

WASHER, PLATE

902010638000 902010638000

Not available

95604-06200-00 *

956070620000 956070620000

4,12 $

Unit Price

BOLT, SMALL FLANGE

950270801600 950270801600

3,84 $

Unit Price

SEAT LEVER BRACKET

5PX2475H0000 5PX2475H0000

102,92 $

Unit Price

BOLT, SMALL FLANGE

950270801600 950270801600

3,84 $

Unit Price

SUPPORT 6

5PX2475R0000 5PX2475R0000

Not available

BOLT, SMALL FLANGE

950270801600 950270801600

3,84 $

Unit Price

PROTECTOR, 1

5PX2476U0000 5PX2476U0000

28,67 $

Unit Price

PROTECTOR, 2

5PX2476V0000 5PX2476V0000

11,98 $

Unit Price

SEAT BRACKET 1

5PX213410000 5PX213410000

52,53 $

Unit Price

SEAL 2

5PX217350000 5PX217350000

Not available

BOLT, FLANGE (8AB)

958170802000 958170802000

3,33 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the SEAT of your Yamaha XV17PCS of 2004. Let us know if you have any questions.
