GEAR SHIFT SHAFT / LEVER

FRAME FOR YAMAHA XVS 2016

FENDER

Item numbers

FRAME COMP.

3D8211104000 3D8211104000

4 313,07 $

Unit Price

DOWN TUBE COMP.2

3D8211501100 3D8211501100

750,26 $

Unit Price

90110-10017-00 *

901101001600 901101001600

5,70 $

Unit Price

ENGINE STAY 3

3D8213171000 3D8213171000

352,52 $

Unit Price

PROTECTOR

3MA274910000 3MA274910000

5,83 $

Unit Price

BOLT, HEXAGON SOCK

901111002800 901111002800

14,08 $

Unit Price

90111-10030-00 *

901111002900 901111002900

6,44 $

Unit Price

ENGINE STAY 5

3D8213140000 3D8213140000

24,09 $

Unit Price

95812-10020-00 *

901051019500 901051019500

6,80 $

Unit Price

FLANGE BOLT

901051204300 901051204300

17,78 $

Unit Price

NUT, SELF-LOCKING

901851200200 901851200200

12,77 $

Unit Price

ENGINE STAY 3

3D8213160000 3D8213160000

30,77 $

Unit Price

95812-10020-00 *

901051019500 901051019500

6,80 $

Unit Price

FLANGE BOLT

901051204400 901051204400

19,82 $

Unit Price

NUT, SELF-LOCKING

901851200200 901851200200

12,77 $

Unit Price

FLANGE BOLT

901051204500 901051204500

30,54 $

Unit Price

NUT, SELF-LOCKING

901851200200 901851200200

12,77 $

Unit Price

BRACKET L

3D82119W1000 3D82119W1000

20,35 $

Unit Price

BOLT, BUTTON HEAD

920120601200 920120601200

1,61 $

Unit Price

COIL BRACKET

3D8213590100 3D8213590100

48,39 $

Unit Price

BOLT

913120601400 913120601400

1,36 $

Unit Price

SIDE COVER 5

3D82171E0100 3D82171E0100

30,93 $

Unit Price

SIDE COVER 6

3D82171X0100 3D82171X0100

20,26 $

Unit Price

COLLAR

903870607100 903870607100

9,82 $

Unit Price

RIVET(4JH)

902690707600 902690707600

3,63 $

Unit Price

BOLT, HEXAGON SOCK

901110606100 901110606100

2,82 $

Unit Price

PROTECTOR

3D82117G0000 3D82117G0000

9,59 $

Unit Price

DAMPER

4XY2834E0000 4XY2834E0000

2,19 $

Unit Price

DAMPER

3D82113B0000 3D82113B0000

3,22 $

Unit Price

DAMPER

5H08235YM000 5H08235YM000

3,59 $

Unit Price

PROTECTOR

3MA274910000 3MA274910000

5,83 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
