FRAME FOR YAMAHA XJR 2015

FENDER

CADRE COMP.

2PN211100000 2PN211100000

Not available

TUBE INCLINE COMP. 2

4KG211500033 4KG211500033

Not available

BOLT, FLANGE

958170805500 958170805500

4,12 $

Unit Price

95617-08200-00 *

956070820000 956070820000

7,26 $

Unit Price

BOLT, FLANGE (4LN)

958170802500 958170802500

3,77 $

Unit Price

SUPPORT 1, MOTEUR

4KG213151000 4KG213151000

Not available

FLANGE BOLT

901051031300 901051031300

31,39 $

Unit Price

NUT(4KG)

901791065800 901791065800

3,35 $

Unit Price

HEXAGON SOCKET HEA

901100819900 901100819900

4,14 $

Unit Price

SUPPORT COMP. 1

4KG2140X0000 4KG2140X0000

Not available

SUPPORT COMP. 2

4KG2140Y0000 4KG2140Y0000

Not available

FLANGE BOLT

901051030000 901051030000

11,18 $

Unit Price

NUT(4KG)

901791065800 901791065800

3,35 $

Unit Price

FLANGE BOLT

901051040200 901051040200

9,73 $

Unit Price

FLANGE BOLT

901051242500 901051242500

10,31 $

Unit Price

COLLERETTE

903871003V00 903871003V00

Not available

SUPPORT MOTEUR COMPLET

5UX214000100 5UX214000100

Not available

COLLERETTE

903871003W00 903871003W00

Not available

FLANGE BOLT

901051060900 901051060900

6,23 $

Unit Price

90179-10658-00 *

901791024700 901791024700

3,35 $

Unit Price

FLANGE BOLT

901051032300 901051032300

11,13 $

Unit Price

WASHER, PLAIN

929071020000 929071020000

3,78 $

Unit Price

CONDUIT 1

5EA2838N0000 5EA2838N0000

Not available

CONDUIT 2

5EA2838R0000 5EA2838R0000

Not available

BOLT, WITH WASHER

901190605400 901190605400

0,62 $

Unit Price

GROMMET (4FU)

904801356700 904801356700

8,80 $

Unit Price

COVER

4BH2219X0000 4BH2219X0000

37,71 $

Unit Price

PROTECTOR

3D82117G0000 3D82117G0000

9,59 $

Unit Price

JEU DE CARENAGE

2PN217A00000 2PN217A00000

Not available

RIVET

902690600200 902690600200

4,24 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRAME of your Yamaha XJR1300C of 2015. Let us know if you have any questions.
