GEAR SHIFT SHAFT / LEVER

FRAME FOR YAMAHA FJR AS ABS 2013

FENDER

FRAME COMP.

3P6211100000

3P6211100200

5 439,36 $

Unit Price

CADRE ARRIERE COMP.

1MD211900000 1MD211900000

Not available

PROTECTOR

3P6216520000 3P6216520000

0,84 $

Unit Price

MEMBER 1

1MD2115A0000 1MD2115A0000

341,14 $

Unit Price

SCREW(4DN)

901490602200

901490630200

6,93 $

Unit Price

CROSS-TUBE

3P6211190000 3P6211190000

619,22 $

Unit Price

WASHER, PLATE (17K)

90201100L300

90201106F200

3,75 $

Unit Price

GUIDE, WIRE

1MC213390000 1MC213390000

19,70 $

Unit Price

BOLT, FLANGE

958121003000

958171003000

7,08 $

Unit Price

BOLT, SOCKET

901100807600

913170802500

5,68 $

Unit Price

BOULON

913121003500 913121003500

Not available

NUT, S-L FLANGE

956021020000 956021020000

5,20 $

Unit Price

CAP

5YU2143A0000 5YU2143A0000

9,57 $

Unit Price

BOLT

913121205500 913121205500

6,78 $

Unit Price

WASHER(6TA)

929021260000

929071260000

2,13 $

Unit Price

COLLAR

903871312P00 903871312P00

24,06 $

Unit Price

91312-08030

913120803000 913120803000

5,18 $

Unit Price

BOLT, WASHER BASED(1UF)

901051041600 901051041600

18,24 $

Unit Price

NUT

901791002500 901791002500

9,67 $

Unit Price

BOLT, ENGINE ADJUSTING

4C8214950000 4C8214950000

22,85 $

Unit Price

BOLT, WASHER BASED(4KM)

901051073000

901051078100

19,86 $

Unit Price

SPACER(3LN)

905601036400 905601036400

18,88 $

Unit Price

BOLT, FLANGE

950220803500 950220803500

3,05 $

Unit Price

STAY, ENGINE 2

3P6213150000 3P6213150000

22,43 $

Unit Price

BOLT

913121002000 913121002000

3,51 $

Unit Price

BOLT, SOCKET

913120801600

913170801600

5,61 $

Unit Price

STAY, ENGINE 3

5JW213160000 5JW213160000

137,68 $

Unit Price

BOLT, HEX. SOCKET BUTTON

901111004700 901111004700

5,67 $

Unit Price

BOLT, WASHER BASED(36Y)

901050830700 901050830700

6,13 $

Unit Price

GUIDE, AIR

3P62137Y0000 3P62137Y0000

67,39 $

Unit Price

SEAL

3P6212690000 3P6212690000

1,68 $

Unit Price

SEAL, AIR

3P6214690000 3P6214690000

10,24 $

Unit Price

NUT, SPRING(4ES)

901830605300

901830606900

3,20 $

Unit Price

BOLT, WITH WASHER(2WG)

901190617200 901190617200

3,94 $

Unit Price

COVER, SHAFT 1

2D22147J0000 2D22147J0000

86,60 $

Unit Price

RIVET

902690700800 902690700800

3,91 $

Unit Price

WASHER, PLATE (8A4)

902020605800 902020605800

4,53 $

Unit Price

BRACKET 3

5JW2118U0000 5JW2118U0000

23,24 $

Unit Price

BRACKET, INNER 1

5JW2113N0000 5JW2113N0000

53,95 $

Unit Price

BOLT, FLANGE

950220601200 950220601200

1,04 $

Unit Price

BRACKET, INNER 2

5JW2113R0000

5JW2113R0100

42,79 $

Unit Price

BRACKET, INNER 2

5JW2113R1000

5JW2113R1100

43,51 $

Unit Price

BOLT, FLANGE

901050607800

950220601200

1,04 $

Unit Price

CAP

5JW2143A0000 5JW2143A0000

35,08 $

Unit Price

DAMPER

5JW218520000 5JW218520000

16,68 $

Unit Price

STAY 3

5JW283580000 5JW283580000

16,19 $

Unit Price

DAMPER 4

5JW284350000 5JW284350000

2,48 $

Unit Price

BOLT, SOCKET

913120601200

913170601200

5,10 $

Unit Price

GUIDE, AIR 3

1MC2137K0000

1MC2137K0100

22,15 $

Unit Price

DAMPER 4

3WF153370100 3WF153370100

6,84 $

Unit Price

RIVET(4KM)

902690507400 902690507400

2,06 $

Unit Price

BOLT, FLANGE

958020601400

958170601400

4,16 $

Unit Price

COLLAR

903870606600 903870606600

3,89 $

Unit Price

STAY 1

1MC283210000 1MC283210000

320,83 $

Unit Price

DAMPER

13S216490000 13S216490000

2,50 $

Unit Price

DAMPER 2

3C5216390000 3C5216390000

4,77 $

Unit Price

STAY, GUIDE 1

1MC2831E0000 1MC2831E0000

14,46 $

Unit Price

SEAL 1

5YU223580000 5YU223580000

3,93 $

Unit Price

BOLT, FLANGE

958220601400

958170601400

4,16 $

Unit Price

COLLAR

903870610700 903870610700

9,23 $

Unit Price

NUT, SPRING

901830507600

90183050A600

4,94 $

Unit Price

RIVET, BLIND (8K1)

902674007600 902674007600

7,43 $

Unit Price

PLATE 1

1MC283960000 1MC283960000

40,58 $

Unit Price

BOLT, FLANGE

958220601400

958170601400

4,16 $

Unit Price

WASHER, PLATE 1UY

90201060L500 90201060L500

3,29 $

Unit Price

BRACKET 5

1MC2836H0000

1MC2836H0100

19,15 $

Unit Price

COLLAR

903870503500 903870503500

6,10 $

Unit Price

BOLT, BUTTON HEAD

920120501200 920120501200

1,47 $

Unit Price

STAY 2

5JW283570000

5JW283570100

27,66 $

Unit Price

DAMPER 3

5JW284250000 5JW284250000

0,76 $

Unit Price

BOLT, FLANGE

950220601000 950220601000

1,04 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRAME of your Yamaha FJR1300AS of 2013. Let us know if you have any questions.
