COVER - ENGINE 1

KICK STARTER FOR YAMAHA XJR 1999

STARTER CLUTCH

Item numbers

IDLER GEAR 1

36Y155120100 36Y155120100

81,17 $

Unit Price

SHAFT 1

36Y155210100 36Y155210100

17,86 $

Unit Price

STOPPER PLATE

2H7155310000 2H7155310000

3,02 $

Unit Price

97017-06012-00 *

970270601200 970270601200

2,38 $

Unit Price

STARTER CLUTCH OUTER ASSY

4KM155800000 4KM155800000

GEAR, IDLER 2 (45T)

4KG155170000 4KG155170000

Not available

WHEEL, STARTER

4KG155240000 4KG155240000

Not available

SHOCK ABSORBER 1

4H7161550100 4H7161550100

5,33 $

Unit Price

SPROCKET, STARTER 2

36Y155190000 36Y155190000

Not available

COLLAR

90387201L200 90387201L200

25,03 $

Unit Price

SHAFT 2

3CV155220000 3CV155220000

112,08 $

Unit Price

PLUG

903311503900 903311503900

7,41 $

Unit Price

BEARING

933062054500 933062054500

74,24 $

Unit Price

O-RING

932104744000 932104744000

4,53 $

Unit Price

93306-00426-00 *

933060040100 933060040100

38,53 $

Unit Price

BEARING HOUSING 1

36Y151630000 36Y151630000

35,23 $

Unit Price

OIL SEAL (4G0)

931022525300 931022525300

17,51 $

Unit Price

SCREW (1KT)

901490622800 901490622800

4,97 $

Unit Price

NOZZLE

36Y134540000 36Y134540000

22,56 $

Unit Price

PRIMARY CHAIN

4FM114560000 4FM114560000

121,49 $

Unit Price

GUIDE, UPPER

36Y114740000 36Y114740000

Not available

97017-06016-00 *

970270601600 970270601600

2,32 $

Unit Price

CIRCLIP (54G)

990096250000 990096250000

8,49 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the KICK STARTER of your Yamaha XJR 1300 SP of 1999. Let us know if you have any questions.
