REAR BRAKE CALIPER

HANDLEBAR & CABLES FOR YAMAHA XMAX 2019

BRAKE MASTER CYLINDER

Item numbers

GUIDON

BL1F61100000 BL1F61100000

Not available

GRIP

2DPF62410000 2DPF62410000

12,96 $

Unit Price

GRIP ASSY

2DPF62400000 2DPF62400000

8,21 $

Unit Price

END, GRIP

1PAF62461000 1PAF62461000

16,05 $

Unit Price

BOLT, HEXAGON SOCKET HEAD(1VJ)

913170603000

901100613800

5,60 $

Unit Price

CABLE D'ACCELERATEUR

BL2F63010100 BL2F63010100

Not available

BOLT, FLANGE

950220601000 950220601000

1,04 $

Unit Price

BOLT, BUTTON HEAD

920170501600 920170501600

0,73 $

Unit Price

HOLDER, WIRE

B74F637G0000 B74F637G0000

6,24 $

Unit Price

BOLT, FLANGE

950220601200 950220601200

1,04 $

Unit Price

REAR VIEW MIRROR ASSY (LEFT)

B74F62800000 B74F62800000

52,85 $

Unit Price

REAR VIEW MIRROR ASSY (RIGHT)

B74F62900000 B74F62900000

52,85 $

Unit Price

COUVERCLE, GUIDON SUP 2

BL2F61440000 BL2F61440000

Not available

VIS, TETE FRAISEE

9016705X0600 9016705X0600

ECROU, RESSORT

9018306X0300 9018306X0300

Not available

NUT, SPRING(1YT)

901830504200 901830504200

1,46 $

Unit Price

COVER, UPPER

B74F62130000 B74F62130000

53,03 $

Unit Price

VIS, TETE FRAISEE

9016705X0600 9016705X0600

RIVET

902690600100 902690600100

4,50 $

Unit Price

COUVERCLE, GUIDON SUP 2

BL1F614500P0 BL1F614500P0

SCREW(4DN)

901490630200 901490630200

6,93 $

Unit Price

RONDELLE, PLATE

9020206X0100 9020206X0100

Not available

TUNING FORK MARK

1PAF836B0000

1PAF836B0100

32,41 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
