KICK STARTER

STARTER CLUTCH FOR YAMAHA XMAX 2018

TRANSMISSION

Item numbers

PIMARY SLIDING SHAVE COMP PRIMARY SLIDING SHEAVE COMP.

1B9E76060000 1B9E76060000

Not available

WEIGHT

1B9E76320100 1B9E76320100

Not available

CAM

1B9E76230000 1B9E76230000

Not available

SLIDER

1B9E76530000 1B9E76530000

Not available

COLLAR

1B9E76450000 1B9E76450000

Not available

WASHER, PLATE

9020112X0700 9020112X0700

Not available

WASHER

1B9E76481000 1B9E76481000

Not available

V-BELT

1B9E76410000 1B9E76410000

Not available

SHEAVE, PRIMARY FIXED

1B9E76111000 1B9E76111000

Not available

NUT

9017012X0100 9017012X0100

Not available

CLUTCH HOUSING COMP.

1B9E66111000 1B9E66111000

Not available

NUT (22F)

901791446900 901791446900

12,89 $

Unit Price

SECONDARY FIXED SHEAVE COMP.

1B9E76601000 1B9E76601000

Not available

SECONDARY SLIDING SHEAVE

1B9E76701000 1B9E76701000

OIL SEAL

931044111900 931044111900

21,13 $

Unit Price

SEAL

1B9E74654000 1B9E74654000

Not available

PIN & COLLAR SET

1B9WE7651000 1B9WE7651000

Not available

SPRING, SECONDARY

1B9E76831000 1B9E76831000

Not available

SEAT, SECONDARY SPRING

1B9E76841000 1B9E76841000

Not available

CLUTCH CARRIER ASSY

1B9E66201000 1B9E66201000

Not available

. SPRING, CLUTCH WEIGHT 1

1B9E66261000 1B9E66261000

Not available

. CIRCLIP

1B9E57443000 1B9E57443000

Not available

NUT

1B9E76681000 1B9E76681000

Not available

SEAL

1B9E74655000 1B9E74655000

Not available

SPACER

1B9E76490000 1B9E76490000

Not available

BEARING

93306906Y200 93306906Y200

Not available

O-RING

9321025X0100 9321025X0100

Not available

O-RING

9321024X0000 9321024X0000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
