ELECTRICAL 1

ELECTRICAL 2 FOR YAMAHA EVOLIS 2017

ELECTRICAL 3

Item numbers

BOBINE D'ALLUMAGE

1C0823100000 1C0823100000

Not available

SUPPORT, BOBINE D'ALLUMAGE

39DH23160000 39DH23160000

Not available

BOLT (7U8)

970800602000 970800602000

5,23 $

Unit Price

BOULON

9010906X2400 9010906X2400

Not available

ANTIPARASITE

4CWH23700100 4CWH23700100

Not available

THERMO UNIT

52BH35910000 52BH35910000

67,20 $

Unit Price

GASKET

904301080400 904301080400

17,30 $

Unit Price

CLAMP

904641000800 904641000800

3,37 $

Unit Price

FAISCEAU DE FILS COMPLET

2DMH25904000 2DMH25904000

Not available

FUSE, 20A-BL

5JJ821512000 5JJ821512000

6,69 $

Unit Price

67F-82151-40-00 *

5JJ821513000 5JJ821513000

4,67 $

Unit Price

FUSE, 7.5A-BL

5JJ821510000 5JJ821510000

6,59 $

Unit Price

FUSE, 30A-BL

5JJ821516000 5JJ821516000

7,72 $

Unit Price

THERMISTOR ASSY

1SDH57000000 1SDH57000000

126,97 $

Unit Price

DIODE ASSY

4WA819800000 4WA819800000

30,66 $

Unit Price

RECTIFIER 2

3WP819800000 3WP819800000

20,60 $

Unit Price

SWITCH, SIDE STAND

32SH25661100 32SH25661100

48,06 $

Unit Price

BOULON, TETE HEXAGONALE CREUSE

9011005X0800 9011005X0800

Not available

95617-05100-00 *

956070510000 956070510000

4,91 $

Unit Price

SUPPORT, RELAIS

1SDH19521000 1SDH19521000

Not available

BOLT

901090625900 901090625900

4,26 $

Unit Price

RELAY ASSY

1TP819500000 1TP819500000

18,82 $

Unit Price

RELAY HOLDER

5EA819520000 5EA819520000

10,22 $

Unit Price

SENSOR, LEAN ANGLE

32PH25760000 32PH25760000

104,46 $

Unit Price

BOULON

9131L0402500 9131L0402500

Not available

WASHER, PLATE

90201047A200 90201047A200

3,96 $

Unit Price

FLASHER RELAY ASSY

3XV833502100 3XV833502100

113,41 $

Unit Price

AVERTISSEUR

52SH33710000 52SH33710000

Not available

9582M-06012-00 *

9580M0601200 9580M0601200

1,33 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
