LEG SHIELD FOR YAMAHA XMAX 2013

WINDSCREEN

PROTEGE-JAMBES 1

37PF83112000 37PF83112000

Not available

CACHE

5B2F83490000 5B2F83490000

Not available

NUT(1KT)

901790552300 901790552300

8,74 $

Unit Price

AMORTISSEUR

37PF83720000 37PF83720000

Not available

PLAQUE, BLOCAGE 3

4HC246180000 4HC246180000

Not available

SCREW, TAPPING(4MV)

977075001600 977075001600

2,15 $

Unit Price

SCREW, TAPPING

901670508000 901670508000

2,52 $

Unit Price

BOULON

9011105X0700 9011105X0700

Not available

ETIQUETTE, AVERTISSEMENT

5WXF15681000 5WXF15681000

Not available

GARNITURE, REPOSE-PIEDS

2ABF74130000 2ABF74130000

Not available

REPOSE-PIEDS

2ABF74510000 2ABF74510000

Not available

GARNITURE, REPOSE-PIEDS

2ABF74230000 2ABF74230000

Not available

REPOSE-PIEDS

2ABF74610000 2ABF74610000

Not available

COLLIER DE BEQUILLE CENTRALE

2ABF71130000 2ABF71130000

Not available

NUT, SPRING(1YT)

901830504200 901830504200

1,46 $

Unit Price

BOULON

9010906X0500 9010906X0500

Not available

JOINT, BOITE 1

37PF838M0000 37PF838M0000

Not available

NUT, SPRING (6E5)

9018305M0200 9018305M0200

1,68 $

Unit Price

JOINT, BOITE 2

37PF839M0000 37PF839M0000

Not available

COUVERCLE

37PF83130000 37PF83130000

Not available

PLAQUE, AVANT

37PF83610000 37PF83610000

Not available

SUPPORT

5B2F83660000 5B2F83660000

Not available

SCREW, TAPPING(4MV)

977075001600 977075001600

2,15 $

Unit Price

ANTIVOL COMPLET

37PWF1790000 37PWF1790000

Not available

PLAQUE

37PF83360000 37PF83360000

Not available

COUVERCLE 3

37PF843JA000 37PF843JA000

Not available

SCREW, TAPPING(4MV)

977075001600 977075001600

2,15 $

Unit Price

SUPPORT

37PF83370000 37PF83370000

Not available

SUPPORT

37PF8337A000 37PF8337A000

Not available

SCREW, TAPPING(4MV)

977075001600 977075001600

2,15 $

Unit Price

PANNEAU, FOURCHE NUE 3

37PF836M0000 37PF836M0000

Not available

NUT, SPRING(1YT)

901830504200 901830504200

1,46 $

Unit Price

HOOK

5GM283790100 5GM283790100

5,12 $

Unit Price

JONC

37PF84570000 37PF84570000

Not available

SCREW, TAPPING(4MV)

977075001600 977075001600

2,15 $

Unit Price

SCREW, TAPPING

901670508000 901670508000

2,52 $

Unit Price

MOULURE 2

37PF83461000 37PF83461000

Not available

MOULURE 4

37PF83481000 37PF83481000

Not available

MOULURE, PROTEGE-JAMBES

37PF833900P6 37PF833900P6

Not available

HOOK

5GM283790100 5GM283790100

5,12 $

Unit Price

COUVERCLE 2

37PF82290000 37PF82290000

Not available

BOLT, BUTTON HEAD

920170502000 920170502000

1,97 $

Unit Price

EMBLEME

2ABF839B0000 2ABF839B0000

Not available

ETIQUETTE, RECOMMANDATION

5DNF415A1000 5DNF415A1000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the LEG SHIELD of your Yamaha YP125R of 2013. Let us know if you have any questions.
