RADIATOR / HOSES FOR YAMAHA XMAX 2006

OIL PUMP

RADIATEUR COMPLET

1B9E24600000 1B9E24600000

Not available

ENS. VENTILATEUR

1B9E24050000 1B9E24050000

Not available

ECROU 1

1B9E26711000 1B9E26711000

Not available

BOULON, FIXATION DE TURBINE

1B9E26750000 1B9E26750000

Not available

PASSE-FIL

9048020X0000 9048020X0000

Not available

GROMMET

904801536300 904801536300

8,72 $

Unit Price

COLLERETTE

9038706X2400 9038706X2400

Not available

90201-06086-00 *

90201060A300 90201060A300

4,35 $

Unit Price

BOLT, FLANGE

9580M0602500 9580M0602500

5,69 $

Unit Price

BOUCHON, RADIATEUR

5MFE24620100 5MFE24620100

Not available

SUPPORT

5MFE25910000 5MFE25910000

Not available

VIS

9014906X0400 9014906X0400

Not available

HOSE 5

1B9E244H0100 1B9E244H0100

Not available

BRIDE, DE DURITE

9045027X0000 9045027X0000

Not available

BRIDE, DE DURITE

9045018X0100 9045018X0100

Not available

DURITE 1

1B9E243A0000 1B9E243A0000

Not available

BRIDE, DE DURITE

9045027X0000 9045027X0000

Not available

DURITE 2

1B9E243E0000 1B9E243E0000

Not available

BRIDE, DE DURITE

9045027X0000 9045027X0000

Not available

PIPE ASSY 1

1B9E248B0000 1B9E248B0000

Not available

BOULON, AVEC RONDELLE

9011906X0200 9011906X0200

Not available

DURITE 2

1B9E24820000 1B9E24820000

Not available

BOULON, AVEC RONDELLE

9011906X0200 9011906X0200

Not available

DURITE 3

1B9E243F0000 1B9E243F0000

Not available

BRIDE, DE DURITE

9045027X0000 9045027X0000

Not available

DURITE4

1B9E244G0000 1B9E244G0000

Not available

BRIDE, DE DURITE

9045027X0000 9045027X0000

Not available

VASE, EXPANSION

1B9F18710000 1B9F18710000

Not available

BOULON, AVEC RONDELLE

9011906X0200 9011906X0200

Not available

CORPS, CABOCHON

1B9F17710000 1B9F17710000

Not available

DURITE

5XLF18170000 5XLF18170000

Not available

JONC

9046710X0100 9046710X0100

Not available

JONC

9046710X0100 9046710X0100

Not available

BRIDE

9046450X0500 9046450X0500

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the RADIATOR / HOSES of your Yamaha YP125R of 2006. Let us know if you have any questions.
