STARTER MOTOR

STARTER CLUTCH FOR YAMAHA DRAGSTAR 2002

TRANSMISSION

PIGNON D ENTRAINEMT PRIMAIRE

5JX161110000 5JX161110000

Not available

KEY, STRAIGHT 584

902820702300 902820702300

13,97 $

Unit Price

WASHER, LOCK

902151615600 902151615600

4,52 $

Unit Price

WASHER, LOCK (30X)

902151622200 902151622200

4,93 $

Unit Price

90170-16311-00 *

901701625600 901701625600

8,86 $

Unit Price

CLOCHE D EMBRAYAGE CPLTE

3KW161500000 3KW161500000

Not available

THRUST PLATE

30X161540000 30X161540000

12,74 $

Unit Price

CLUTCH BOSS

30X163710000 30X163710000

88,12 $

Unit Price

4H7-16321-02-00 *

31A163210100 31A163210100

23,11 $

Unit Price

3J2-16324-10-00 *

3J2163240000 3J2163240000

22,39 $

Unit Price

PRESSURE PLATE 1

30X163510200 30X163510200

47,03 $

Unit Price

SPRING, COMPRESSIO

905012614800 905012614800

9,76 $

Unit Price

SCREW & WASHER 1W4

901590601600 901590601600

3,87 $

Unit Price

PUSH PLATE

1W1163580100 1W1163580100

13,19 $

Unit Price

PUSH ROD 1

4DN163560000 4DN163560000

16,56 $

Unit Price

WASHER (6TA)

929070620000 929070620000

2,04 $

Unit Price

95317-06600-00 *

953070660000 953070660000

2,01 $

Unit Price

ROD PUSH SEAL

3YX1635A0000 3YX1635A0000

15,68 $

Unit Price

4H7-16321-02-00 *

31A163210100 31A163210100

23,11 $

Unit Price

WASHER, LOCK (30X)

902151632000 902151632000

8,27 $

Unit Price

NUT

901701632600 901701632600

14,48 $

Unit Price

PUSH LEVER ASSY

2UJ163800000 2UJ163800000

87,25 $

Unit Price

SCREW

901490806700 901490806700

4,53 $

Unit Price

GASKET, O/P UNIT B

904300811900 904300811900

Not available

TORSION SPRING

905081443300 905081443300

3,24 $

Unit Price

CIRCLIP

934202805500 934202805500

2,07 $

Unit Price

OIL SEAL

931021420900 931021420900

14,15 $

Unit Price

BEARING, CYLINDRIC

933153142800 933153142800

22,56 $

Unit Price

PUSH ROD 2

2UJ163570000 2UJ163570000

22,56 $

Unit Price

93511-32027-00 *

935113201700 935113201700

4,96 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the STARTER CLUTCH of your Yamaha XVS125 of 2002. Let us know if you have any questions.
