CATALOGUE

CYLINDER HEAD FOR YAMAHA TZ 1997

CRANKSHAFT / PISTON

CULASSE

4JT111111000 4JT111111000

Not available

O-RING

932106344200 932106344200

11,53 $

Unit Price

O-RING

932108869600 932108869600

8,22 $

Unit Price

BOUGIE D, ALLUMAGE (R6385-105P)

947020037300 947020037300

Not available

DOWEL PIN (278)

936040807100 936040807100

4,89 $

Unit Price

FLANGE BOLT

90105063A000 90105063A000

3,23 $

Unit Price

GASKET

904300616600 904300616600

Not available

CYLINDRE

4DP113101100 4DP113101100

Not available

BINDING SCREW

989070502000 989070502000

2,32 $

Unit Price

AXE 1

3LC1131V0000 3LC1131V0000

Not available

OIL SEAL 8X12X3-37

931040804000 931040804000

15,48 $

Unit Price

SOUPAPE 1

3YL1131A0100 3YL1131A0100

Not available

SUPPORT 1

1RK1131E0000 1RK1131E0000

Not available

DOWEL PIN

936042625600 936042625600

1,26 $

Unit Price

BINDING SCREW

989070501000 989070501000

0,94 $

Unit Price

BUSH, SOLID (3LC)

903800819200 903800819200

23,09 $

Unit Price

CIRCLIP (22K)

934400813000 934400813000

0,62 $

Unit Price

90201-08085-00 *

902010840300 902010840300

5,45 $

Unit Price

POULIE 1

4DP1132E0000 4DP1132E0000

Not available

VIS

901490514900 901490514900

Not available

95817-06010-00 *

958270601000 958270601000

2,20 $

Unit Price

GASKET

904300616600 904300616600

Not available

SUPPORT 1

3XV119980000 3XV119980000

Not available

BOLT, SOCKET

913170501000 913170501000

2,51 $

Unit Price

CABLE, POULIE 1

4JT1133E1000 4JT1133E1000

Not available

CABLE 2

4JT1133F1000 4JT1133F1000

Not available

GASKET, CYLINDER

4JT113510200 4JT113510200

35,49 $

Unit Price

GASKET, CYL (0.7T)

4JT113511200 4JT113511200

32,90 $

Unit Price

JOINT, D EMBASE (0.6T)

4JT113512200 4JT113512200

Not available

STUD BOLT

901160840900 901160840900

6,21 $

Unit Price

NUT, FLANGE (JN5)

957070850000 957070850000

1,67 $

Unit Price

99530-10114-00 *

995101011400 995101011400

3,55 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CYLINDER HEAD of your Yamaha TZ125 of 1997. Let us know if you have any questions.
