WATERPUMP

RADIATOR / HOSES FOR YAMAHA TZR 1992

OIL PUMP

BOLT, HEXAGON

973010603000

970170602500

2,42 $

Unit Price

WASHER PLATE 137241870000

902010607200 902010607200

2,78 $

Unit Price

COLLAR

903870638800

903870615800

2,96 $

Unit Price

GROMMET (29L)

904801536300 904801536300

9,09 $

Unit Price

RADIATEUR COMPLET

3MA124600000 3MA124600000

Not available

CAP, RADIATOR

1KT124620000

4FL124620000

62,69 $

Unit Price

JOINT

4DLF12680000 4DLF12680000

Not available

JONC 90467-10001-BL

904671000100 904671000100

Not available

HOSE 615243132000

904450900100

904450910200

4,39 $

Unit Price

DURITE 2

4DLE24820000 4DLE24820000

Not available

HOSE CLAMP ASSY

904502801400

904502800100

16,37 $

Unit Price

DURITE 1

4DLE24810000 4DLE24810000

Not available

HOSE CLAMP ASSY

904502801400

904502800100

16,37 $

Unit Price

SCREW, PAN

985060601200

985170601200

2,10 $

Unit Price

DURITE 3

4DLE24830000 4DLE24830000

Not available

O-RING(3LD)

932101232700

932101279000

3,58 $

Unit Price

BRIDE, DE DURITE

904503001400 904503001400

Not available

SCREW, PAN

985060602000

985170602000

4,41 $

Unit Price

RACCORD 1

3NCE24690000 3NCE24690000

Not available

JOINT, COUVERCLE

3NCE24140000 3NCE24140000

Not available

GASKET (4V2)

904300616600 904300616600

3,85 $

Unit Price

BOULON, RACCORD

904010604200 904010604200

Not available

CLIP (3G0)

904671003500

904671003900

6,46 $

Unit Price

DURITE 4

3NCE24840000 3NCE24840000

Not available

BOULON, RACCORD

904010604200 904010604200

Not available

O-RING(1KT)

932102719400

932102777800

6,67 $

Unit Price

THERMOSTAT

34X124110000

34X124110100

47,62 $

Unit Price

BRIDE, DE DURITE 90450-26001-BL BRIDE, DE DURITE 90450-26001-B

904502600100 904502600100

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the RADIATOR / HOSES of your Yamaha TZR125R of 1992. Let us know if you have any questions.
