INTAKE

CARBURETOR FOR YAMAHA TDR 1992

EXHAUST

.BOISSEAU 1 (40) BOISSEAU 1 (40)

3SHE41120000 3SHE41120000

Not available

.JEU D AIGUILLES (X 69/3) JEU D AIGUILLES (X 69/3)

3XEE490J0000 3XEE490J0000

Not available

.PUITS D AIGUILLE PUITS D AIGUILLE

3XEE41416400 3XEE41416400

Not available

.GICLEUR, PRINCIPAL ((105 GICLEUR, PRINCIPAL ((105

3XEE41430000 3XEE41430000

Not available

GICLEUR, RALENTI (42)

3SHE41424200 3SHE41424200

Not available

.PLONGEUR, STARTER (60) PLONGEUR, STARTER (60)

3SHE41710000 3SHE41710000

Not available

.POINTEAU POINTEAU

3SHE41900000 3SHE41900000

Not available

.FLOTTEUR GR. 6.5 FLOTTEUR GR. 6.5

3XEE41850000 3XEE41850000

Not available

.ECROU, REGLAGE DE CABLE ECROU, REGLAGE DE CABLE

2AHE41610000 2AHE41610000

Not available

.ECROU, FIXATION ECROU, FIXATION

2AHE41640000 2AHE41640000

Not available

.JOINT JOINT

2AHE41650000 2AHE41650000

Not available

.RESSORT, BOISSEAU RESSORT, BOISSEAU

2AHE41310000 2AHE41310000

Not available

.BUTEE DE CABLE BUTEE DE CABLE

2AHE41320000 2AHE41320000

Not available

.RESSORT, VIS DE DOSAGE D AIR RESSORT, VIS DE DOSAGE D AIR

2AHE41340000 2AHE41340000

Not available

.JEU DE STATERS JEU DE STATERS

3SHE410A0000 3SHE410A0000

Not available

.PLOT, VIDANGE PLOT, VIDANGE

3SHE41910000 3SHE41910000

Not available

.LEVIER DE STARTER COMPLET LEVIER DE STARTER COMPLET

3SHE42010000 3SHE42010000

Not available

.JEU DE VIS DE DOSAGE D AIR JEU DE VIS DE DOSAGE D AIR

2AHE41040000 2AHE41040000

Not available

.SIEGE, RESSORT SIEGE, RESSORT

2AHE41360000 2AHE41360000

Not available

.JONC JONC

2AHE41370000 2AHE41370000

Not available

.JEU DE VIS D ACCELERATION JEU DE VIS D ACCELERATION

3XEE41030000 3XEE41030000

Not available

.JONC, PLONGEUR JONC, PLONGEUR

2AHE41380000 2AHE41380000

Not available

.JONC DE DURITE JONC DE DURITE

2AHE41390000 2AHE41390000

Not available

.CORPS, CUVE DE FLOTTEUR 1 CORPS, CUVE DE FLOTTEUR 1

2AHE41810000 2AHE41810000

Not available

.COUVERCLE, CUVE DE FLOTTEUR COUVERCLE, CUVE DE FLOTTEUR

2AHE41820000 2AHE41820000

Not available

.RONDELLE, POINTEAU RONDELLE, POINTEAU

2AHE41950000 2AHE41950000

Not available

.DURITE DURITE

2AHE41970000 2AHE41970000

Not available

.AXE, FLOTTEUR AXE, FLOTTEUR

2AHE41860000 2AHE41860000

Not available

.PLAQUE PLAQUE

2AHE41460000 2AHE41460000

Not available

2AHE40001400 2AHE40001400

Not available

CARBURATEUR 1 COMPLET

3XEE41011000 3XEE41011000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CARBURETOR of your Yamaha TDR125R of 1992. Let us know if you have any questions.
