ELECTRICAL 1

ELECTRICAL 2 FOR YAMAHA V1 2015

ELECTRICAL 3

Item numbers

ACCEL. POSITON SENSOR ASSY

6D3143052100 6D3143052100

793,12 $

Unit Price

NUT, NYLON (6J8)

957800830000 957800830000

12,44 $

Unit Price

RIVET (EU0)

90267489U100

902674893800

4,53 $

Unit Price

BRACKET, THROTTLE

F2NU72540000 F2NU72540000

19,35 $

Unit Price

CLAMP(3XW)

904643513200 904643513200

2,72 $

Unit Price

IGNITION COIL ASSY

6D3823100100 6D3823100100

334,09 $

Unit Price

BOLT, FLANGE(JL8)

958800601600 958800601600

6,33 $

Unit Price

SPARK PLUG CR9EB

947020040900

NGKCR9EB0100

6,88 $

Unit Price

WIRE HARNESS ASSY 1

6BU8259L2000 6BU8259L2000

2 986,23 $

Unit Price

BAND, SWITCH CORD

9046513M2400

437839361100

4,65 $

Unit Price

THERMOSENSOR ASSY

61A857900000

61A857900100

180,04 $

Unit Price

WASHER, PLATE

929901060000 929901060000

3,94 $

Unit Price

THERMO SWITCH ASSY

60E82560A100 60E82560A100

160,45 $

Unit Price

BOLT, HEXAGON W-W DEEP RECESS

975950641600

97E950641600

2,15 $

Unit Price

HOSE(6M6)

9044614M2300

9044617M1100

4,71 $

Unit Price

THERMO SWITCH ASSY

6D3825600100 6D3825600100

197,67 $

Unit Price

BOLT, HEXAGON W-W DEEP RECESS

975950641600

97E950641600

2,15 $

Unit Price

SENSOR, CAM POSITION

6D3858960000

6D3858960100

347,55 $

Unit Price

BOLT, SOCKET

913800601600 913800601600

0,80 $

Unit Price

OIL PRESSURE SWITCH ASSY

68V825040000 68V825040000

130,75 $

Unit Price

LEAD WIRE ASSY

60E813150000

60E813150100

88,58 $

Unit Price

CAP

60E825320000

60E825320100

12,98 $

Unit Price

EARTH PLATE COMP.

6D38273J0100

6D38273J0200

322,34 $

Unit Price

O-RING(61A)

9321060ME800 9321060ME800

11,96 $

Unit Price

BOLT, WITH WASHER

901190604800 901190604800

3,22 $

Unit Price

CLAMP

9046513M1800 9046513M1800

2,40 $

Unit Price

CLAMP

904644500200 904644500200

11,54 $

Unit Price

BAND

904651315200

1UA825910000

3,11 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the ELECTRICAL 2 of your Yamaha V1 of 2015. Let us know if you have any questions.
