CONTROL CABLE

STEERING 1 FOR YAMAHA VX1050E-R 2016

STEERING 2

Item numbers

HANDLE

F2NU15520000 F2NU15520000

419,78 $

Unit Price

GRIP, HANDLE

GP7U155D0100 GP7U155D0100

80,90 $

Unit Price

GRIP, END

GP7U155F0000 GP7U155F0000

7,55 $

Unit Price

BOLT, HEXAGON SOCKET HEAD

901100590800 901100590800

4,13 $

Unit Price

THROTTLE LEVER ASSY

F0D672501000 F0D672501000

173,28 $

Unit Price

LEVER, THROTTLE

F0D672550200 F0D672550200

41,85 $

Unit Price

SPRING

EW2672560000 EW2672560000

7,11 $

Unit Price

WASHER, PLAIN (646)

EW2672580100

929900560000

1,09 $

Unit Price

CIRCLIP (EU0)

EW2672590100

990800460000

1,68 $

Unit Price

SHAFT

F0D672570000 F0D672570000

22,82 $

Unit Price

BOLT, THROTTLE

F1X6725F0100 F1X6725F0100

7,72 $

Unit Price

SWITCH BOX ASSY

FK7683100700 FK7683100700

367,96 $

Unit Price

LANYARD, STOP SWITCH

EW2683480000 EW2683480000

52,94 $

Unit Price

SCREW, PAN HEAD (J10)

978800300800

985800300800

2,10 $

Unit Price

STOP BUTTON COMP

FK7683120200 FK7683120200

16,81 $

Unit Price

START BUTTON COMP.

FK7683130200 FK7683130200

19,13 $

Unit Price

SCREW, PANHEAD (A93)

978800502500

985800552500

3,98 $

Unit Price

STEERING MASTER AS

F2X614001000

Not available

SHAFT

F2X6152D0000 F2X6152D0000

435,53 $

Unit Price

HOUSING ASSY

F2X6152M0000

F2X6152M0200

333,19 $

Unit Price

BUSH

F1K6134M0000 F1K6134M0000

13,46 $

Unit Price

BAND

703825910000

1UA825910000

3,11 $

Unit Price

SPACER, BRKT.

F2P6146H0000 F2P6146H0000

17,13 $

Unit Price

SCREW, OVAL HEAD

F1B613C10000

Not available

ARM ASSY.

F1K6153R0000

F1K6153R0100

179,37 $

Unit Price

STUD, JOINT BALL

EU0614610200 EU0614610200

25,70 $

Unit Price

NUT, NYLON (EU0)

957200630000 957200630000

4,32 $

Unit Price

BOLT

F1K613550000 F1K613550000

26,65 $

Unit Price

PLATE, RETAINING

F1K6142B0000 F1K6142B0000

11,86 $

Unit Price

NUT, NYLON (EU0)

957200830000 957200830000

10,01 $

Unit Price

BUZZER

F1S683410000 F1S683410000

180,13 $

Unit Price

SENSOR, MAGNET

F2X6838B0000

F2X6838B0200

203,22 $

Unit Price

SCREW

F2X613C10000 F2X613C10000

5,08 $

Unit Price

MAGNET

F2X6838C0000

F2X6838C0100

69,17 $

Unit Price

SEAL, RUBBER

F1K6143C0000 F1K6143C0000

66,21 $

Unit Price

BRACKET, STOPPER CABLE

F1KU14670100 F1KU14670100

90,72 $

Unit Price

RIVET, BLIND(EW2)

90267489U200 90267489U200

3,30 $

Unit Price

BOLT WITH WASHER

901190883600 901190883600

9,77 $

Unit Price

STOPPER, CABLE

F1KU14680300 F1KU14680300

13,39 $

Unit Price

BOLT WITH WASHER

90119069UH00

Not available

HOLDER, HANDLE UPPER

EU0238143100

EU0238143200

29,41 $

Unit Price

BOLT, WITH WASHER

901190882700

901190884400

10,37 $

Unit Price

PLUG

F1KU19490000 F1KU19490000

12,92 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
