FRONT BRAKE MASTER CYLINDER

STAND / FOOTREST FOR YAMAHA FAZER 2006

REAR BRAKE MASTER CYLINDER

STAND, SIDE

2D1273110000 2D1273110000

109,10 $

Unit Price

BRACKET, SIDE STAND

2D1273210000 2D1273210000

128,72 $

Unit Price

BOLT

901011000600

901011002500

10,83 $

Unit Price

NUT, U

901851003700 901851003700

9,07 $

Unit Price

WASHER, PLATE

902011602000

902011602700

6,22 $

Unit Price

SPRING, TENSION

905061800800 905061800800

20,01 $

Unit Price

HOSE (L60)

904451900200 904451900200

5,79 $

Unit Price

COLLAR

903871005000 903871005000

15,65 $

Unit Price

WASHER, PLATE(47X)

90201101J100 90201101J100

6,46 $

Unit Price

BOLT, SOCKET

901101001000

913171003000

6,02 $

Unit Price

FRONT FOOTREST ASSY (LEFT)

2D1274100000 2D1274100000

100,47 $

Unit Price

COVER, FOOTREST

4BP274130000 4BP274130000

37,09 $

Unit Price

PAN HEAD SCREW 3YL

901570502500

985800501400

3,94 $

Unit Price

BOLT

90109083E200

901090817700

6,13 $

Unit Price

BRACKET 2

2D1274420000

2D1274420100

158,16 $

Unit Price

DAMPER, FOOTREST 2

1NL274240000 1NL274240000

34,64 $

Unit Price

STOPPER, MAIN STAND

5VX271140000 5VX271140000

2,52 $

Unit Price

COVER 1

2D1274860000 2D1274860000

32,65 $

Unit Price

PLATE, FOOTREST

1HX274150000 1HX274150000

1,71 $

Unit Price

BOLT, BUTTON HEAD

901110501500

920140500800

0,72 $

Unit Price

BOLT, HEX. SOCKET BUTTON

90109103A900

901111001700

5,28 $

Unit Price

WASHER, WAVE(46X)

902061708400 902061708400

9,24 $

Unit Price

BOLT, HEXAGON SOCKET HEAD(38V)

901100807100 901100807100

8,56 $

Unit Price

WASHER(1UF)

902090829500 902090829500

7,75 $

Unit Price

FRONT FOOTREST ASSY (RIGHT)

2D1274200000 2D1274200000

97,36 $

Unit Price

COVER, FOOTREST

4BP274130000 4BP274130000

37,09 $

Unit Price

PAN HEAD SCREW 3YL

901570502500

985800501400

3,94 $

Unit Price

BOLT

90109083E200

901090817700

6,13 $

Unit Price

BRACKET 3

2D1274430000

2D1274430100

207,37 $

Unit Price

DAMPER, FOOTREST 2

1NL274240000 1NL274240000

34,64 $

Unit Price

STOPPER, MAIN STAND

5VX271140000 5VX271140000

2,52 $

Unit Price

BOLT, HEX. SOCKET BUTTON

90109103A900

901111001700

5,28 $

Unit Price

WASHER, WAVE(46X)

902061708400 902061708400

9,24 $

Unit Price

STAY, STOP SWITCH

2D12144G0000 2D12144G0000

29,14 $

Unit Price

SCREW, PAN

985070600800

985170600800

2,10 $

Unit Price

COVER 2

2D1274870000 2D1274870000

32,65 $

Unit Price

PLATE, FOOTREST

1HX274150000 1HX274150000

1,71 $

Unit Price

BOLT, BUTTON HEAD

901110501500

920140500800

0,72 $

Unit Price

BOLT, HEXAGON SOCKET HEAD(38V)

901100807100 901100807100

8,56 $

Unit Price

WASHER(1UF)

902090829500 902090829500

7,75 $

Unit Price

FOOTREST, REAR 1

3VR274310100

3VR274310200

43,58 $

Unit Price

BRACKET 4

2D12741L0000 2D12741L0000

239,01 $

Unit Price

SPRING, COMPRESSION (22N)

905011274300 905011274300

3,98 $

Unit Price

BALL

935010401100 935010401100

0,74 $

Unit Price

WASHER, SPECIAL

5VX274370000 5VX274370000

10,13 $

Unit Price

PIN, CLEVIS

917020804000 917020804000

3,88 $

Unit Price

PIN, COTTER

914012501500

914902502000

3,93 $

Unit Price

FOOTREST, REAR 2

3VR274410100

3VR274410200

43,58 $

Unit Price

BRACKET 5

2D12742L0000 2D12742L0000

261,84 $

Unit Price

SPRING, COMPRESSION (22N)

905011274300 905011274300

3,98 $

Unit Price

BALL

935010401100 935010401100

0,74 $

Unit Price

WASHER, SPECIAL

5VX274370000 5VX274370000

10,13 $

Unit Price

PIN, CLEVIS

917020804000 917020804000

3,88 $

Unit Price

PIN, COTTER

914012501500

914902502000

3,93 $

Unit Price

DAMPER, FOOTREST 2

36Y274240100 36Y274240100

20,26 $

Unit Price

COLLAR (2H7)

903871063600 903871063600

16,15 $

Unit Price

BOLT

90109085G600 90109085G600

6,80 $

Unit Price

WASHER, PLATE (2H7)

902011066900 902011066900

7,43 $

Unit Price

BOLT, FLANGE

958141004000 958141004000

5,12 $

Unit Price

STAND, MAIN

3C3271110000 3C3271110000

365,40 $

Unit Price

STOPPER, MAIN STAND

371271140000 371271140000

12,04 $

Unit Price

BRACKET, MAIN STAND

3C3271510100 3C3271510100

368,21 $

Unit Price

BRACKET, MAIN STAND 2

3C3271520000 3C3271520000

131,47 $

Unit Price

BOLT(1TX)

90109101E600 90109101E600

22,83 $

Unit Price

NUT, SELF-LOCKING(JN5)

956071020000 956071020000

4,90 $

Unit Price

BEACKET, ADAPTER 1

3C3274A30000 3C3274A30000

66,15 $

Unit Price

BOLT

901011000400 901011000400

4,13 $

Unit Price

NUT, SELF-LOCKING(JN5)

956071020000 956071020000

4,90 $

Unit Price

SPRING, TENSION

905064000700 905064000700

42,33 $

Unit Price

SPRING, TENSION

905062301000 905062301000

11,83 $

Unit Price

HOSE (L75)

904451900300 904451900300

5,51 $

Unit Price

BOLT

901011000400 901011000400

4,13 $

Unit Price

NUT, SELF-LOCKING(JN5)

956071020000 956071020000

4,90 $

Unit Price

BOLT, HEXAGON SOCKET HEAD

90109105G700

901101001200

2,07 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the STAND / FOOTREST of your Yamaha FZ1S of 2006. Let us know if you have any questions.
