GEAR SHIFT SHAFT / LEVER

FRAME FOR YAMAHA VIRAGO 1987

FENDER

CADRE COMP.

1AT211100033 1AT211100033

Not available

SUPPORT 3, MOTEUR

42X213170000 42X213170000

Not available

SUPPORT, BOBINE

42X213590000 42X213590000

Not available

SCREW, PAN

925060601200

985170601200

2,10 $

Unit Price

WASHER(6A1)

929060610000

929950610000

1,46 $

Unit Price

WASHER(6TA)

929060660000

929070660000

1,83 $

Unit Price

BOLT, WASHER BASED(42X)

901051029700 901051029700

11,04 $

Unit Price

NUT, CROWN(2GG)

901761004900

901761007500

10,04 $

Unit Price

NUT(3EF)

901791242100

901791265700

7,77 $

Unit Price

WASHER, PLATE (5E3)

90201125A300 90201125A300

4,33 $

Unit Price

ENGINE STAY 2

42X213150000

42X213150100

38,99 $

Unit Price

ENGINE STAY 3

42X213160000

42X213160100

53,17 $

Unit Price

BOULON, AVEC RONDELLE

901051029800 901051029800

Not available

WASHER, PLATE(42X)

90201105H300 90201105H300

7,76 $

Unit Price

COLLAR (5E3)

90387100E200 90387100E200

4,71 $

Unit Price

AMORTISSEUR, CAOUTCHOUC 1

4X7214850000 4X7214850000

Not available

BOLT, FLANGE(6TA)

901051029900

958171011000

7,77 $

Unit Price

BOLT, WASHER BASED(42X)

901051030000 901051030000

11,66 $

Unit Price

BRACKET, SIDE STAND

42X214580100 42X214580100

137,44 $

Unit Price

NUT, CROWN(2GG)

901761004900

901761007500

10,04 $

Unit Price

BOLT, WASHER BASED HEXAGON 1L9

901050606900 901050606900

4,00 $

Unit Price

WASHER, PLATE(3MB)

902020601000

902020518700

1,68 $

Unit Price

PLUG 288833190000

903380704300 903380704300

3,08 $

Unit Price

BRIDE

904620813800 904620813800

Not available

SCREW, PAN TAP.2

977065050800

977075050800

0,69 $

Unit Price

COVER 2

42X2139R0000

2AE2139R0000

27,96 $

Unit Price

SCREW, BINDING

989060601000

989070601000

2,29 $

Unit Price

WASHER, PLATE (4L0)

90201062A800 90201062A800

1,68 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRAME of your Yamaha XV1000 of 1987. Let us know if you have any questions.
