STAND / FOOTREST

LEG SHIELD FOR YAMAHA JOG 2005

COVER 1

Item numbers

PROTEGE-JAMBES COMPLET

5WYF83000000 5WYF83000000

Not available

CACHE

4KLF83491000 4KLF83491000

Not available

TAPPING SCREW (4MV

977075001600 977075001600

2,06 $

Unit Price

CROCHET 1

5WYF82570000 5WYF82570000

Not available

SCREW & WASHER 676

901590681200 901590681200

4,36 $

Unit Price

TAPPING SCREW (4MV

977075001600 977075001600

2,06 $

Unit Price

CONDUIT, AIR

5WYF15570000 5WYF15570000

Not available

BRIDE DE DURITE

5WYF18230000 5WYF18230000

Not available

SUPPORT, CABLE

5WYF11610000 5WYF11610000

Not available

BOLT, WITH WASHER

975070551000 975070551000

0,65 $

Unit Price

PROTEGE-JAMBES COMPLET

3D3X283000FE 3D3X283000FE

Not available

PROTEGE-JAMBES COMPLET

3D3X283000P4 3D3X283000P4

Not available

PROTEGE-JAMBES COMPLET

3D3X283000P5 3D3X283000P5

Not available

. EMBLEME

5WYF411B0000 5WYF411B0000

Not available

. EMBLEME

5WYF839B0000 5WYF839B0000

Not available

PROTECTEUR 1

5WYF834V0000 5WYF834V0000

Not available

SCREW & WASHER 676

901590681200 901590681200

4,36 $

Unit Price

TAPPING SCREW (4MV

977075001600 977075001600

2,06 $

Unit Price

CATADIOPTRE

5WYH51100000 5WYH51100000

Not available

NUT, U FLANGE

956070520000 956070520000

4,52 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Yamaha, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
