SWITCH / LEVER

ELECTRICAL 1 FOR YAMAHA CHAMP 1991

ELECTRICAL 2

Item numbers

BLOC C.D.I.

3GB855400000 3GB855400000

Not available

SCREW PAN HEAD

925010602000

985800602000

5,09 $

Unit Price

WASHER(6A1)

929900610000

929950610000

1,46 $

Unit Price

WASHER, PLAIN (646)

929900660000 929900660000

2,09 $

Unit Price

IGNITION COIL ASSY

2UV82310M000

3KJ823101300

60,54 $

Unit Price

BOLT, HEXAGON DEEP RECESS

973130601600

97D950601600

1,96 $

Unit Price

SCREW (5G3)

901530603400 901530603400

3,22 $

Unit Price

PLUG CAP ASSY

55X823700000

4BP823700100

41,76 $

Unit Price

NEUTRAL SWITCH ASSY

3GB825400000

3GB825400100

28,15 $

Unit Price

GASKET (5R6)

904301002700

904301017100

6,32 $

Unit Price

REDRESSEUR REGULATEUR CPLT

3GB819600000 3GB819600000

Not available

SCREW PAN HEAD

925020601600

985800601600

2,35 $

Unit Price

WASHER(6A1)

929900610000

929950610000

1,46 $

Unit Price

STARTER RELAY ASSY (MS5D-611)

3AY819400000

4KD819400000

71,90 $

Unit Price

NUT(650)

953030670000

953800670000

4,53 $

Unit Price

WASHER(6A1)

929900610000

929950610000

1,46 $

Unit Price

RELAY ASSY

1RL819509100

12R819500200

159,43 $

Unit Price

BAT 12N7D-3B (12N7D-3B) YU NA

55X82110G000

12N7D3B00000

112,85 $

Unit Price

HOSE (L1500)

90445085E000

90445084J000

21,15 $

Unit Price

WIRE, PLUS LEAD

55X821150000

55X821150100

23,96 $

Unit Price

WIRE, MINUS LEAD

3GB821160000 3GB821160000

20,13 $

Unit Price

BAND, BATTERY

4J2821310100 4J2821310100

15,49 $

Unit Price

SIEGE, BATTERIE

55X821220000 55X821220000

Not available

DAMPER 1

29W821230000

1UY216380000

1,44 $

Unit Price

FUSE HOLDER ASSY

3GB821500000 3GB821500000

61,75 $

Unit Price

FUSE (12V 5A)

3GB821510000

5G2821510000

3,02 $

Unit Price

FEU DE POSITION CPLT

55X835300000 55X835300000

Not available

CORDON CPLT

55X835200000 55X835200000

Not available

TAIL LIGHT BULB T-10 12V 3.4W

4G1847440000 4G1847440000

4,55 $

Unit Price

FAISCEAU DE FILS COMPLET

3GB825900000 3GB825900000

Not available

BAND, SWITCH CORD

437839361000

437839361100

4,65 $

Unit Price

BAND, SWITCH CORD

25G839360000

25G839360100

6,05 $

Unit Price

CLAMP

437839360000

904643001400

1,33 $

Unit Price

CLAMP

437839360000

904643001400

1,33 $

Unit Price

MAIN SWITCH ASSY

2FJ825100100

2FJ825100900

156,01 $

Unit Price

CAP, KEY

24W825790000 24W825790000

29,35 $

Unit Price

ETIQUETTE

29U835851000 29U835851000

Not available

COLLIER

1UY825910000 1UY825910000

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the ELECTRICAL 1 of your Yamaha YFM100 of 1991. Let us know if you have any questions.
