STARTER MOTOR

STARTER CLUTCH FOR YAMAHA AG 1996

TRANSMISSION

Item numbers

CLOCHE D'EMBRAYAGE CPLTE

3V6161500000 3V6161500000

Not available

THRUST PLATE

276161540000 276161540000

14,97 $

Unit Price

MOYEU D'EMBRAYAGE

1E7163710000 1E7163710000

Not available

FRICTION PLATE

3HA163210000 3HA163210000

24,77 $

Unit Price

137-16324-10-00 *

137163240000 137163240000

22,39 $

Unit Price

CUSHION RING

137163670000 137163670000

15,59 $

Unit Price

PRESSURE PLATE

132163510000 132163510000

42,39 $

Unit Price

SPRING, COMPRESSIO

905012012400 905012012400

5,43 $

Unit Price

BOLT WITH WASHER

901190500100 901190500100

6,45 $

Unit Price

NUT HEX (13716377)

901701206000 901701206000

3,68 $

Unit Price

WASHER 16416119000

902081201500 902081201500

2,18 $

Unit Price

PIGNON, PRIMAIRE 17 DTS.

382161116200 382161116200

Not available

NUT HEX (13716377)

901701206000 901701206000

3,68 $

Unit Price

RONDELLE, GROWER CONIQUE

902081201800 902081201800

Not available

THRUST PLATE

122161640000 122161640000

5,68 $

Unit Price

SPACER 164-16181-0

905601714600 905601714600

27,90 $

Unit Price

PUSH ROD 1

137163560000 137163560000

19,14 $

Unit Price

BALL

935010401100 935010401100

0,71 $

Unit Price

PUSH ROD 2

276163570000 276163570000

9,74 $

Unit Price

SEAL, PUSH ROD

931090606000 931090606000

5,31 $

Unit Price

PUSH SCREW

241163410100 241163410100

14,96 $

Unit Price

SET BOLT 241163430

901130601300 901130601300

3,88 $

Unit Price

LEVIER, DEBRAYAGE

382163426100 382163426100

Not available

NUT (JN5)

953170670000 953170670000

2,01 $

Unit Price

SPRING, TENSION 13

905061001900 905061001900

2,97 $

Unit Price

SPRING HOOK

132163460000 132163460000

2,95 $

Unit Price

OIL SEAL

931041008500 931041008500

13,06 $

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Yamaha. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the STARTER CLUTCH of your Yamaha AG 100 of 1996. Let us know if you have any questions.
